05701-A-0326 | Honeywell Field Interface Card SYS57

Product Overview

The Honeywell 05701-A-0326 is a Field Interface Card (sensor input only, no relays) for the System 57 gas detection platform. It provides direct interface connections between the control card and field-connected gas sensors without relay outputs, serving as a pure signal routing and termination module.

Key Specifications

• Model Number: 05701-A-0326
• Series: Honeywell System 57
• Product Type: Field Interface Card — No Relays, Sensor Input Only
• Power Consumption: 0.0W (passive interface)
• Dimensions: 112 mm × 25 mm × 102 mm (H × W × D)
• Weight: 95g
• Field Terminals: 2.5 mm² (14 AWG)
• Status: Phased Out — available via factory replacement service

Core Features

• Direct sensor input termination without relay outputs
• Passive interface with zero power consumption
• Compact and lightweight design
• Provides clean signal path from field sensors to control cards
• Compatible with all System 57 sensor drive modules

Applications

• Gas sensor signal routing in non-alarm applications
• Systems using external relay panels
• Signal monitoring without local alarm output requirements
• Cost-effective sensor interface solutions

FAQ

Q: Does the 05701-A-0326 provide relay outputs?
A: No, this is a sensor input-only interface card. For relay outputs, use 05701-A-0327, 05701-A-0328, 05701-A-0329, or 05701-A-0330.

Q: Is the 05701-A-0326 still in production?
A: This part is phased out but may be available via factory replacement service or authorized surplus suppliers.

Installation Guide

1. Power down the System 57 rack.
2. Insert the field interface card into the appropriate slot.
3. Connect field sensor wiring directly to the terminal block.
4. Verify proper signal continuity to the control card.
5. Power up and perform sensor calibration.

Selection Tips

• Use 05701-A-0326 when only sensor input termination is needed (no local relays).
• For alarm relay outputs, select from the 05701-A-0327 through 05701-A-0330 series.
• Verify availability as this part is phased out; consider 05701-A-0327 as an alternative.
