10004/H/F | Honeywell Communication Interface Module

Product Overview

The Honeywell 10004/H/F is a Communication Interface Module for the Honeywell FSC (Fail Safe Control) system. It serves as a specialized communication processor board that facilitates high-speed data exchange between the FSC safety logic solver and external distributed control systems (DCS), enabling real-time status reporting and remote diagnostic access for safety-critical applications.

Key Specifications

• Model Number: 10004/H/F
• Product Type: Communication Interface Module
• Series: Honeywell FSC (Fail Safe Control)
• Power Consumption: 5V DC at 175mA (per MaxwellPLC); or ~5W typical at 24 VDC (per TopBrandsPLC)
• Communication Protocols: Honeywell proprietary, Modbus RTU/TCP, Ethernet/IP, BACnet
• Interfaces: RS-232, RS-485, Ethernet
• Baud Rate: Up to 115.2 kbps (serial); up to 10 Mbps (Ethernet per some sources)
• Operating Temperature: -20°C to +70°C (per TopBrandsPLC); or -40°C to +75°C (per PLCDCSPro)
• Storage Temperature: -40°C to +85°C
• Humidity: 5–95% non-condensing
• Shock Resistance: 30 g, 11 ms
• Vibration Resistance: 2 g, 10–500 Hz
• Dimensions: ~20.3 × 33.3 × 160 mm (per TopBrandsPLC); or 100 × 60 × 30 mm (per PLCDCSPro)
• Weight: 0.24 kg to 0.5–0.7 kg (varies by source)
• Mounting: DIN rail or panel mount
• Approvals: CE, UL, CSA
• Lifecycle Status: Discontinued by OEM (available as new surplus)

⚠️ Data Uncertainty Notice

Limited official technical data is available from public sources for the 10004/H/F. The specifications above are compiled from multiple authorized industrial automation suppliers (MaxwellPLC, TopBrandsPLC, PLCDCSPro). Some parameters show variation between sources. For critical applications, please contact Honeywell directly or request the official datasheet. The 10004/H/F does not appear in the publicly accessible FSC Hardware Manual sections retrieved.

Core Features

• Multi-protocol communication gateway for FSC safety systems
• Real-time diagnostic access and status reporting
• Redundancy support for high-availability configurations
• Ruggedized design for harsh industrial environments
• Deterministic timing for SIL-rated safety operations

Applications

• Safety instrumented systems (SIS) communication gateway
• Emergency shutdown (ESD) system DCS integration
• Sequence-of-events (SOE) reporting and alarm logging
• Turbine protection and burner management remote monitoring
• Legacy FSC system lifecycle extension

FAQ

Q: Is the 10004/H/F still in production?
A: No, this module has been discontinued by the OEM but is available as new surplus from authorized suppliers.

Q: What is the difference between 10004/H/F and 10024 series?
A: The 10004/H/F is a legacy communication interface module, while the 10024 series are Enhanced Communication Modules (ECM) with more advanced features and flash memory.

Installation Guide

1. Power down the FSC system before installation.
2. Mount the module on DIN rail or panel as required.
3. Connect communication cables (RS-232/RS-485/Ethernet).
4. Configure protocol parameters via FSC engineering software.
5. Verify communication integrity with connected DCS or operator station.

Selection Tips

• For new installations, consider 10024 series Enhanced Communication Modules.
• For legacy FSC system maintenance, the 10004/H/F is a vital replacement part.
• Verify exact dimensional and power requirements with supplier before ordering.
• Consider 10018/E/1 or 10018/2/U as alternative communication modules.
