136188-01 | Bently Nevada | 3500 Series Ethernet Communication Gateway Module

Product Overview

The Bently Nevada 136188-01 acts as a high-speed communication bridge within the 3500 Series Machinery Protection System. This module facilitates the transfer of critical machine health data from the internal backplane to external Ethernet networks. It ensures that host computers and Distributed Control Systems (DCS) receive real-time status updates and static data without interfering with primary protection functions. We provide this component as 100% Brand New original equipment to guarantee the highest cybersecurity and data throughput standards.

Technical Specifications

Engineering Advantages

• Real-Time Data Streaming: The 136188-01 bypasses legacy serial bottlenecks. It streams vibration, position, and temperature data directly to your plant network via robust Ethernet protocols, supporting faster decision-making for plant operators.

• EMI/RFI Hardened Design: High-voltage industrial environments generate significant electrical noise. This module incorporates advanced shielding to maintain signal integrity, ensuring that data transmission remains stable even when located near large motors or variable frequency drives.

• Seamless DCS Integration: The module supports industry-standard Modbus protocols. This allows the 3500 system to talk directly to your PLC or DCS without requiring expensive third-party protocol converters, simplifying the overall system architecture.

• High-Density Cabinet Solution: The compact 136188-01 design optimizes rack real estate. It installs into the standard 3500 chassis without requiring specialized power taps or external cooling hardware, making it ideal for retrofitting existing cabinets with limited space.

FAQs

• Does the 136188-01 require a separate power supply?

  No. The module draws its operating power directly from the 3500 rack backplane. This reduces wiring complexity and ensures that the communication gateway initializes simultaneously with the rest of the machinery protection system.

• How do I configure the IP settings on this module?

  You perform all network configurations using the 3500 Rack Configuration Software. Connecting a configuration PC to the rack allows you to set static IPs or define the Modbus registers for your specific monitoring requirements.

• Is this module a direct replacement for legacy serial interface modules?

  Yes. The 136188-01 provides modern Ethernet capabilities that significantly outperform older RS232/RS485 serial interfaces. It offers higher bandwidth and easier connectivity for modern System 1™ software environments.

• How do I verify that I am receiving a 100% Brand New unit?

  Each 136188-01 ships in original factory-sealed anti-static packaging. The unit includes a verified serial number and date code from the Bently Nevada USA facility, ensuring it has never seen previous field service.
