140DDO84300 Schneider Modicon Quantum DC Output Module

Product Description

The 140DDO84300 is a high-capacity discrete output module for the Schneider Electric Modicon Quantum PLC platform. It provides 32 solid-state 24 VDC output channels for reliable control of field devices such as solenoids, relays, and actuators. Designed for demanding industrial environments, the module integrates robust electrical protection to withstand EMI and harsh operating conditions.

Technical Specifications

Application

Well suited for high-output-density control systems requiring reliable 24 VDC switching, including:

• Process automation and batch control

• Material handling and conveyor systems

• Power generation and auxiliary systems

• Marine and offshore automation

Functional Comparison

140DDO84300 vs 140DDO35300
Both modules support 24 VDC outputs with 32 points. However, the 140DDO84300 delivers 0.5 A per output, compared to 0.25 A per output on the 140DDO35300, making the 84300 better suited for higher-current solenoids and actuator loads.

FAQ

Does this module include output protection?
Yes. Electronic short-circuit protection is built in to safeguard the module against wiring faults.

Which terminal block is required?
The 40-pin Modicon Quantum terminal block (140XTS00200).

Is the module suitable for marine applications?
Yes. RMRS certification confirms compliance with Russian Maritime Register of Shipping requirements.
