140NOE77100 Schneider Electric Ethernet Communication Module
  • 140NOE77100 Schneider Electric Ethernet Communication Module
  • 140NOE77100 Schneider Electric Ethernet Communication Module
  • 140NOE77100 Schneider Electric Ethernet Communication Module
140NOE77100 Schneider Electric Ethernet Communication Module

Schneider

140NOE77100 Schneider Electric Ethernet Communication Module

10 left

  • Manufacturer: Schneider

  • Product No.: 140NOE77100

  • Product Type: Ethernet Communication Module

  • Product Origin: France

  • Payment:T/T, Western Union

  • Weight: 550g

  • Shipping port: Xiamen

  • Warranty: 12 months

Special offer ends!
00 :
00 :
00

Product Description

The 140NOE77100 is an Ethernet communication interface for the Modicon Quantum PLC. It enables integration into industrial networks via Modbus TCP/IP, providing deterministic data exchange, remote diagnostics, and SCADA connectivity. The module supports dual-media (copper RJ45 or fiber MT/RJ) for flexible deployment in electrically noisy or long-distance environments.

Technical Specifications

Item Specification
Protocols Modbus TCP/IP, SNMP, HTTP, FTP, BOOTP/DHCP
Communication Rate 10/100 Mbps (auto-sensing)
Interface Ports 1 × RJ45 (10/100BASE-T), 1 × MT/RJ (100BASE-FX)
Web Server Class B20 (Data Editor, Rack Viewer, Diagnostics)
Max Connections 64 Modbus TCP/IP server connections
I/O Scanning Up to 64 devices, 120 words per read/write
Topology Support Star, Ring (via external switches), Hot Standby (HSBY)
Bus Current Requirement 750 mA @ 5.1 V DC
Module Slot Single Quantum slot
Operating Temperature 0–60 °C
Diagnostics LEDs for Link, Activity, Collision, Module Status, Network Status

Typical Applications

  • Large-scale manufacturing and process plants

  • Power substations and utility automation

  • Intelligent traffic systems and building automation

  • Long-distance or electrically noisy environments using fiber optic links

Notes

  • Dual Media: Only one port (RJ45 or MT/RJ) active at a time; not a switch

  • Firmware Upgrade: Supported via Ethernet or CPU Executive port

  • Ensures deterministic network performance for distributed I/O and SCADA integration
