1746-IO12DC Allen-Bradley SLC 500 Digital I/O Combination Module

Product Overview

The Allen-Bradley 1746-IO12DC serves as a versatile digital I/O combination module designed specifically for the SLC 500 programmable logic controller platform. This compact unit integrates 6 DC inputs and 6 DC outputs into a single chassis slot, significantly optimizing backplane space for small to medium-sized automation systems. Operating on a standard 10-30V DC voltage range, it provides a highly efficient solution for controlling and monitoring 24V DC field devices in diverse industrial applications. We supply this item as a 100% Brand New, factory-sealed unit.

Technical Specifications

Engineering Advantages

Space-Saving Combination Architecture
The 1746-IO12DC maximizes your SLC 500 chassis capacity by combining 6 inputs and 6 outputs into a single I/O slot. This design drastically reduces the physical footprint required for your control system, allowing you to fit more functionality into smaller control panels and minimizing the overall hardware costs of your automation project.

Optimized 24V DC Industrial Control
Engineered for standard industrial logic levels, this module operates seamlessly within a 10-30V DC range. Each of the 6 output channels delivers up to 1.2 amps of current, providing ample power to directly drive solenoids, indicator lights, and small contactors without the need for external intermediate relays.

Efficient Backplane Integration
Drawing only 60-80 milliamps from the SLC 500 backplane, the 1746-IO12DC maintains high energy efficiency. This low power consumption ensures stable operation across your entire PLC rack, preventing power supply overloads even when multiple combination modules are installed side-by-side.

FAQs

Q: How many input and output points does the 1746-IO12DC provide?
A: This combination module provides a total of 12 digital points, consisting of 6 DC inputs and 6 DC outputs, all housed within a single SLC 500 I/O slot.

Q: What is the operating voltage range for this module?
A: The 1746-IO12DC operates on a flexible 10 to 30 Volts DC range, making it perfectly compatible with standard 24V DC industrial control systems and field devices.

Q: How much current can each output channel handle?
A: Each of the 6 output channels can source up to 1.2 amps at 24V DC. This capacity is sufficient for driving most standard industrial DC loads directly.

Q: What is the signal delay for the 1746-IO12DC?
A: The module features a signal delay of 8 milliseconds, ensuring predictable and stable response times for general-purpose industrial automation and machine control applications.
