1761-L32BWA | Allen-Bradley | MicroLogix 1000 Programmable Controller

Product Overview

The Allen-Bradley 1761-L32BWA serves as a high-density, standalone controller within the MicroLogix 1000 family. It provides a cost-effective solution for small-scale automation by integrating 20 DC inputs and 12 robust relay outputs into a single, compact chassis. This unit operates on standard AC line voltage, making it ideal for localized control panels in material handling and packaging applications. We supply this product as 100% Brand New and Original, ensuring your legacy systems remain operational with factory-certified hardware.

Technical Specifications

Engineering Advantages

• Integrated Power Efficiency: The built-in AC power supply accepts a wide range of voltages (85–264V AC). This eliminates the need for separate 24V DC power modules, reducing both bill-of-materials costs and cabinet complexity.

• Non-Volatile Data Security: The controller utilizes EEPROM memory to store user programs and data. This technology retains logic indefinitely without a battery, protecting your process against data loss during extended power outages.

• Mechanical Installation Versatility: The 1761-L32BWA supports both horizontal and vertical mounting orientations. This flexibility allows engineers to fit the controller into shallow or awkwardly shaped enclosures common in retrofit projects.

• Rugged Output Switching: The 12 relay outputs interface directly with diverse AC and DC loads. This mechanical switching capability handles high inrush currents from solenoids and starters better than transistor-based alternatives.

FAQs

• Q: Does the 1761-L32BWA require a backup battery for its memory?

  A: No. The unit uses internal EEPROM memory to store the application runtime and instruction words. This non-volatile storage eliminates the maintenance burden and risks associated with lithium battery failure.

• Q: Can I mix different voltages on the relay outputs?

  A: Yes. Because the relay outputs provide mechanical isolation, you can switch different voltage levels across the output groups. However, you must observe the specified current limits for each contact to prevent premature relay wear.

• Q: What is the benefit of "Sinking Inputs" for this model?

  A: Sinking inputs allow the controller to complete the circuit when a field device (like a NPN sensor) provides a path to the common ground. This standard interface ensures compatibility with a vast range of industrial proximity and limit switches.

• Q: How many program cycles can this controller handle?

  A: The 1761-L32BWA features a minimum power cycle rating of 50,000 cycles. This high durability rating ensures long-term performance in environments where the equipment undergoes daily start-up and shut-down routines.
