1B30035H01 | Emerson Ovation Process Control Base Rev 05

Emerson Ovation 1B30035H01 I/O Process Control Base Module

The 1B30035H01 (Part # 1B30035H01) is a specialized 2-slot Process Control Base designed for the Emerson Ovation™ Distributed Control System (DCS). Serving as a critical foundation within the Ovation I/O subsystem, this base provides the physical and electrical interface required for electronics modules to communicate with the controller. It is engineered to facilitate reliable signal conditioning and data acquisition, ensuring that field device information is accurately processed for mission-critical applications in power generation and utility infrastructure.

Technical Specifications

The following technical parameters define the operational limits and physical characteristics of the 1B30035H01 (Revision 05).

• Manufacturer: Emerson (Ovation™ Series)

• Model Number: 1B30035H01

• Module Type: I/O Process Control Base

• Slot Configuration: 2-Slot Standard Base

• Power Handling: 9 KVA Capacity

• Voltage Rating: 480 V (Standard System Rating)

• Signal Capacity: Typically supports 16–32 channels depending on the electronics module populated

• A/D Resolution: 12-bit or higher (Application dependent)

• Accuracy: ±0.1% of full scale typical

• Isolation: Channel-to-channel and channel-to-system electrical isolation

• Operating Temperature: 0°C to +60°C

• Storage Temperature: –40°C to +85°C

• Humidity: 5–95% non-condensing

• Mounting: Standard Ovation rack/cabinet mounting

• Weight: 0.88 kg (1.94 lbs)

• Revision Status: Rev 05 (Refined hardware version)
