1C31199G04 Westinghouse Ovation Servo Driver DC LVDT

Emerson Ovation 1C31199G04 – Servo Driver Electronics Module

The Emerson Ovation 1C31199G04 is a Servo Driver Electronics Module in the Ovation DCS family. It is a revision-variant of the 1C31199G0x series, providing electronic signal processing for servo drive loops in turbine control and precision motion applications.

• Module Type: Servo Driver Electronics Module
• Supply Voltage: 24 VDC nominal
• Operating Temperature: −40°C to +70°C
• Storage Temperature: −40°C to +85°C
• Dimensions: 121 mm × 25 mm × 70 mm
• Shock Resistance: 10 g half-sine wave for 11 ms
• Mounting: Standard Ovation I/O rack
• Communication: Ovation backplane interface

Technical Specifications

FAQ

1. Module Function
   The 1C31199G04 is a servo driver electronics module. It processes control signals for servo drive loops in turbine valve positioning and motion control applications.
2. G04 vs G01 Replacement
   G04 is a later hardware revision in the 1C31199G0x series. It is functionally compatible with G01 servo applications using the same personality file and wiring.
3. Application Areas
   This module is found in turbine control systems, valve positioning loops, and specialized motion control applications within the Ovation DCS.
4. Hot-Swap Support
   Hot-swap support depends on chassis revision. Consult the Ovation I/O base manual for the specific hardware version.

Installation Guide
