2711-T10C16 | Allen-Bradley | PanelView 1000 Standard Operator Terminal

Product Overview

The Allen-Bradley 2711-T10C16 serves as a high-performance Human-Machine Interface (HMI) within the PanelView 1000 Standard Terminal product line. This operator terminal executes local plant-floor diagnostics, visualizes real-time machine processes, and transmits operator commands directly to automation controllers. It interfaces with legacy and modern systems via standard point-to-point DF1 serial networks, providing clear multi-color graphic representation of industrial operations.

Technical Specifications

Engineering Advantages

• High-Durability Touch Matrix: The analog resistive touchscreen contains 384 individual touch cells ($26 \times 30$ pixels each). This resolution registers operator inputs precisely, even when workers wear heavy industrial gloves in harsh processing environments.

• Universal AC Input Power: The internal power supply accepts voltages ranging from 85V AC to 264V AC. This wide tolerance prevents terminal resets or screen flickering during severe line-voltage drops or frequency shifts.

• Harsh Enclosure Protection: When engineers mount this terminal using the factory-supplied sealing gasket, the front bezel achieves NEMA Type 4X, 12, and 13 ratings. This barrier prevents water washdowns, corrosive chemical splashing, and airborne conductive dust from entering the electronics.

• Dedicated Diagnostics and Printing: Dual independent RS-232 ports allow simultaneous network communication and local data logging. The primary DF1 port maintains continuous controller interaction while the secondary port drives a local serial printer for instant hardcopy alarm logging.

FAQs

• Although Rockwell Automation marks the 2711-T10C16 as discontinued, can I still obtain a brand new unit?

  Yes. We specialize in sourcing hard-to-find components and guarantee this 2711-T10C16 arrives in 100% brand new, original factory-sealed condition. It does not consist of surplus, refurbished, or used parts.

• What software do engineers use to modify application screens for this terminal?

  PanelBuilder32 software configures the screens, alarm lists, and memory tags for the entire PanelView Standard series. The terminal downloads these configuration files through the primary RS-232 serial port.

• How does this unit handle grounding inside a noisy electrical panel?

  The rear chassis features a dedicated, low-impedance functional earth screw. Technicians must connect a heavy-gauge copper wire from this screw directly to the main enclosure ground busbar to block electromagnetic interference (EMI) from corrupting the internal logic boards.
