2711P-RDT12C | Allen-Bradley | PanelView Plus 6 1250 Color Touch Display Module

Product Overview

The 2711P-RDT12C functions as the primary visual interface for the Allen-Bradley PanelView Plus 6 1250 series. This 12.1-inch color display module utilizes high-sensitivity touch technology to provide operators with real-time process visualization and machine control. It serves as a field-replaceable component, allowing for the rapid upgrade or repair of existing HMI terminals without replacing the entire logic assembly. We provide this module as 100% Brand New original stock, ensuring crisp image clarity and responsive touch performance for your critical automation systems.

Technical Specifications

The 2711P-RDT12C delivers industrial-grade visualization through the following parameters:

• Display Size: 12.1-inch Diagonally Measured

• Input Type: Analog Resistive Touch Screen

• Resolution: 800 x 600 SVGA

• Display Type: Active Matrix Color TFT

• Backlight: Field Replaceable CCFL or LED (Series Dependent)

• Supply Voltage: 85-264 VAC (Via Logic Module Connection)

• Internal Memory: 128 MB (Shared with logic module)

• Communication Support: Ethernet, RS-232, and USB (Via Logic Module)

• Weight: 5.00 lbs (2.27 kg)

Engineering Advantages

• Modular Component Integration: The 2711P-RDT12C features a modular design that connects seamlessly to PanelView Plus 6 logic modules. This architecture enables technicians to replace only the display module in the event of screen damage or backlight failure, significantly reducing maintenance costs and hardware waste.

• High-Resolution Visualization: The 800 x 600 resolution provides sharp graphical representations of complex industrial processes. This clarity ensures that operators can identify subtle alarm indicators and data trends quickly, improving response times in high-speed manufacturing environments.

• Ruggedized Touch Interface: The resistive touch screen operates reliably even when used with industrial gloves or in environments with airborne contaminants. It withstands the daily mechanical stress of high-frequency input, ensuring long-term tactical feedback accuracy.

• Direct Drop-in Replacement: This module fits standard PanelView 1250 cutouts. It eliminates the need for panel modifications or recutting when servicing discontinued or older 1250 systems, allowing for a clean and efficient installation that maintains the NEMA enclosure rating.

FAQs

• Is the 2711P-RDT12C supplied as a brand new original unit?

  Yes. We supply this display module as 100% Brand New original factory stock. Despite the manufacturer's discontinued status for this series, our units remain in original, unused condition to provide a high-reliability replacement option for your existing systems.

• Does this part number include the logic module or power supply?

  No. The 2711P-RDT12C identifies the Display Module Only. To form a complete HMI terminal, you must attach a compatible PanelView Plus 6 logic module (e.g., 2711P-RP8D or similar) and the appropriate communication internal components.

• Can I use this module to replace a non-touch (Keypad) 1250 display?

  You can install this module into a chassis previously using a keypad display, but the application software (FactoryTalk View ME) must be configured for touch input. Additionally, ensure your existing logic module supports touch-screen signal processing to maintain full functionality.

• What is the recommended cleaning procedure for the touch surface?

  Clean the screen using a soft, lint-free cloth dampened with a mild, non-abrasive glass cleaner or isopropyl alcohol. Avoid spraying liquids directly onto the display seams to prevent moisture ingress into the internal circuitry.
