2711P-RN3 | Allen-Bradley | PanelView Plus DH-485 Communication Module

Overview

The Allen-Bradley 2711P-RN3 is a communication module designed for PanelView Plus operator terminals. Supporting the DH-485 network protocol, it provides reliable connectivity for PanelView Plus 400 and 600 models. With plug-and-play installation and LED indicators for status monitoring, this module ensures seamless integration into industrial HMI systems.

Technical Specifications

• Manufacturer: Allen-Bradley (Rockwell Automation)

• Model/Part Number: 2711P-RN3

• Product Type: Communication Module

• Product Line: PanelView Plus

• Communication Protocol: DH-485

• Compatible Terminals: PanelView Plus 400, PanelView Plus 600

• Cable Length: 30 m maximum

• Installation: Plug-and-play design

• Indicator Type: LED status indicator

• Weight: 0.19 lbs (0.09 kg)

• Operating Temperature: 0–55 °C

• Storage Temperature: -25–70 °C

• Relative Humidity: 5–95% non-condensing

• Shock Resistance:

• Operating: 15 G

• Non-operating: 30 G

Key Features

• DH-485 protocol support for legacy network integration

• LED indicators for quick diagnostics

• Compact and lightweight design

• Simple plug-and-play installation

• Compatible with PanelView Plus 400 and 600 HMIs

Applications

• Industrial HMI communication for PanelView Plus terminals

• Legacy system integration requiring DH-485 protocol

• Control panels and machine-level operator interfaces

• Environments requiring reliable communication modules

FAQ

• Q: Which PanelView models are supported?  A: PanelView Plus 400 and 600.

• Q: What communication protocol does it use?  A: DH-485 network protocol.

• Q: How is the module installed?  A: Plug-and-play installation with LED indicators for status.

• Q: What is the maximum cable length supported?  A: Up to 30 meters.
