2711P-RP1 PanelView Plus Logic Module 64MB RAM/Flash | Allen-Bradley

Product Overview

The Allen-Bradley 2711P-RP1 functions as the core processing engine for the PanelView Plus series of operator interfaces. This logic module houses the CPU, system memory, and communication interfaces required to execute complex HMI applications. It specifically powers the larger-format PanelView Plus terminals ranging from the 700 to the 1500 models. We provide this unit in 100% Brand New condition, ensuring pristine internal circuitry and maximum processing longevity for your visualization infrastructure.

Technical Specifications

• Module Type: Logic Module (DC Powered)

• Compatible Terminals: PanelView Plus 700, 1000, 1250, and 1500

• RAM Capacity: 64 MB

• Flash Capacity: 64 MB

• Input Voltage: DC Voltage

• Operating Temperature: 0 to 55 °C (32 to 131 °F)

• Operating Shock: 15 G for 11 ms

• Non-Operating Shock: 30 G for 11 ms

• Relative Humidity: 5% to 95% (Non-condensing)

• Max Altitude: 2000 m above sea level

• Weight: 2.00 lbs (0.91 kg)

Engineering Advantages

The 2711P-RP1 addresses specific maintenance and upgrade challenges through its modular hardware architecture:

• Modular Restoration Strategy: The separate logic module design allows for the independent replacement of the processor without discarding the expensive display module. This architecture significantly reduces repair costs and minimizes hardware waste when troubleshooting system failures.

• Optimized Shock Resistance: This module withstands operating shocks up to 15 G. This mechanical resilience ensures stable processor performance in high-vibration environments, such as those found in stamping plants or near heavy reciprocating machinery.

• Seamless Integration with Large Displays: The hardware specifically manages the graphics rendering requirements for displays up to 15 inches. It ensures smooth screen transitions and rapid alarm response across high-resolution HMI applications.

• Standardized Footprint for PanelView Plus: The 2711P-RP1 fits the standard mounting interface of the original PanelView Plus 700–1500 series. This standardization enables a "plug-and-play" installation process, allowing maintenance teams to restore machine operations without modifying the existing panel cutout or wiring.

FAQs

• Which PanelView models support the 2711P-RP1?

  This logic module works exclusively with the DC-powered versions of the PanelView Plus 700, 1000, 1250, and 1500 terminals. It serves as the standard 64MB processing unit for these specific display sizes.

• Is this a Brand New original product or a refurbished module?

  We guarantee this 2711P-RP1 is 100% Brand New and remains in its original factory state. Using new logic modules prevents the common failure points found in used units, such as degraded memory sectors or weakened power capacitors.

• Does the 2711P-RP1 include the display module?

  No. The 2711P-RP1 is the logic module only. You must mate this module to a compatible PanelView Plus display module to create a complete, functioning operator terminal.

• How do I install the 2711P-RP1 onto the display?

  Align the 2711P-RP1 with the back of the display module and secure it using the integrated screws. Ensure you apply power only after the two modules are firmly seated and locked together to prevent electrical arcing or data corruption.
