2711P-RP8D | Allen-Bradley | PanelView Plus 6 Logic Module

Product Overview

The Allen-Bradley 2711P-RP8D functions as the core processing engine for the PanelView Plus 6 terminal series. This 100% brand new original logic module provides the computational power, memory management, and communication interfaces required to run complex HMI applications. By integrating high-speed RAM and non-volatile flash memory, it ensures rapid screen transitions and stable data logging for demanding industrial automation environments.

Technical Specifications

• Manufacturer: Allen-Bradley / Rockwell Automation

• Part Number: 2711P-RP8D

• Series: PanelView Plus 6

• Input Voltage: 18-32V DC

• Power Consumption: 70W (Max)

• RAM (Installed): 512 MB

• Non-Volatile Memory: 512 MB Flash

• On-Board Communication: 1 x RJ-45 (Ethernet), 1 x 9-pin D-Shell (RS-232)

• Protocols: EtherNet/IP, DF1

• USB Ports: 1 x USB 2.0, 2 x USB Host

• Real-Time Clock: Integrated

• Configuration Software: FactoryTalk View Studio Machine Edition

• Shipping Weight: 5.0 kg

Engineering Advantages

• Enhanced Data Processing: The 512MB RAM architecture handles intensive graphic objects and large alarm logs without latency. This ensures the HMI remains responsive even during peak network traffic or high-tag-count operations.

• Flexible Communication Architecture: Dual on-board ports support simultaneous connection to modern EtherNet/IP networks and legacy serial DF1 devices. This eliminates the need for external protocol converters in hybrid control systems.

• Robust Memory Reliability: The 512MB non-volatile flash memory protects critical application data and system settings against power loss. This hardware design maintains system integrity without requiring constant battery backup for the application files.

• Simplified Field Upgrades: The module attaches directly to the back of PanelView Plus 6 displays. This modular design allows engineers to upgrade the logic performance or replace communication components without replacing the entire HMI touchscreen assembly.

FAQs

• Is this 2711P-RP8D logic module brand new?

  Yes, we provide only 100% brand new, original Allen-Bradley hardware in factory-sealed packaging to ensure maximum operational reliability.

• Which software do I use to configure this module?

  This module requires FactoryTalk View Studio Machine Edition (ME) for application development and runtime configuration.

• Does this unit support USB peripherals?

  The hardware includes one USB 2.0 port and two USB host ports, allowing you to connect external storage, keyboards, or mice for enhanced operator interaction.

• What is the power requirement for the 2711P-RP8D?

  The module operates on a DC power range of 18-32V DC. Ensure your power supply can handle the 70W peak consumption to maintain stable HMI performance.
