2711P-T7C15D1 | Allen Bradley | PanelView Plus 700 Color Touchscreen Terminal

Product Overview

The Allen Bradley 2711P-T7C15D1 functions as a high-performance Human Machine Interface (HMI) within the legacy PanelView Plus 700 series. This 6.5-inch operator terminal executes complex plant monitoring, data visualization, and localized machine control algorithms by communicating directly with ControlLogix and PLC-5 systems over a deterministic ControlNet network. Although the original manufacturer classifies this specific hardware series as discontinued, we supply this critical interface in 100% brand new, original factory stock to keep your legacy production lines operational without forcing an expensive, system-wide architecture upgrade.

Technical Specifications

Engineering Advantages

• Deterministic ControlNet Architecture Integration: The native ControlNet port manages critical data exchange with scheduled I/O networks. This localized interface guarantees predictable, high-speed delivery of machine alerts, system parameters, and diagnostic bits without data packet collisions common on unmanaged Ethernet networks.

• Responsive Multi-Touch Surface Configuration: The analog resistive touchscreen registers immediate operator inputs even when layered with grease, industrial dust, or humidity. It eliminates input errors on the plant floor by allowing flawless button actuation from operators wearing heavy protective industrial gloves.

• Low-Profile Enclosure for Compact Cutouts: The slim physical framing houses the 6.5-inch screen, internal memory, and network processors within a single compact block. This layout allows engineers to mount the terminal directly into tight control cabinet doors or localized operator pendant stations where panel depth is highly restricted.

• Stable DC Power Filtration: The internal power regulator accepts a wide input window from 18V to 32V DC. This fluctuating voltage tolerance protects the HMI's internal 64 MB memory chip and CPU from common battery bank drops or sudden DC bus voltage spikes caused by nearby inductive load switching.

FAQs

• Is this 2711P-T7C15D1 HMI a repaired or refurbished unit?

  No. We guarantee this terminal is 100% brand new, original factory-sealed stock. It arrives in its authentic Rockwell Automation box with the unblemished manufacturer label, original serial number sequence, and protective clear screen film intact.

• Which software do I require to modify or restore the application screens?

  You must use Rockwell Automation’s FactoryTalk View Machine Edition (ME) software to build, edit, and download runtime application files (.MER files) into the terminal's 64 MB internal memory.

• How do I replace the display backlight if the bulb fails in the field?

  You do not need to replace the entire HMI chassis. The modular engineering design allows technicians to remove the rear housing and swap out the worn lighting unit with a brand new, standard 2711P-RL7C2 replacement backlight assembly.

• Can I link this terminal to an SLC 500 controller via the ControlNet port?

  Yes. You can establish high-speed data links to an SLC 500 platform by using a compatible external communication interface module, such as the 1747-KFC15A communication cable assembly, to manage the network mapping.
