3500/05-01-02-00-00-01 | Bently Nevada 3500 Series System Rack

Product Overview

The Bently Nevada 3500/05-01-02-00-00-01 serves as the central physical and electrical backbone for the 3500 Machinery Protection System. This 19-inch EIA-compliant full-size rack houses up to 14 monitor modules, power supplies, and communication gateways. It provides the high-speed backplane necessary for real-time data exchange and synchronized alarm processing across the entire machinery train. We provide this rack in 100% brand new, original condition, ensuring a high-performance foundation for critical industrial monitoring.

Part Number Breakdown: 3500/05-01-02-00-00-01

• 3500/05: System Rack Main Series.

• -01: 19-inch Rack Size (Standard EIA framing).

• -02: Full-Size Rack Mount Option (Secures to standard 19-inch EIA rails).

• -00: No Agency Approvals (Standard non-hazardous configuration).

• -00: Reserved / None.

• -01: European Compliance Option (CEE).

Technical Specifications

• Manufacturer: Bently Nevada (Baker Hughes)

• Chassis Capacity: 14 available slots for power, interface, and monitoring modules

• Mounting Standard: 19-inch EIA Rack Mount

• Compliance: CEE (European Compliance)

• Interface: High-speed digital backplane for inter-module communication

• Bus Architecture: Distributes DC power and system-wide clock signals to all slots

• Condition: 100% Brand New, Factory Original

• Warranty: 1 Year

Engineering Advantages

The 3500/05-01-02-00-00-01 streamlines machinery protection through specialized industrial design:

• Maximum Rack Density: The 14-slot configuration enables comprehensive monitoring of complex machinery—including steam turbines, centrifugal compressors, and multi-stage pumps—within a single unified chassis. This reduces the number of separate enclosures required in the control room.

• European Regulatory Alignment: The CEE compliance option ensures the rack meets specific European electrical and safety standards. This simplifies the import and commissioning process for facilities operating within the EU or utilizing European engineering specifications.

• EMI/RFI Suppression: The rugged backplane incorporates specialized shielding layers. This construction blocks electromagnetic interference from variable frequency drives (VFDs) and high-voltage switchgear, preventing false trips or signal degradation.

• Scalable Power Distribution: The integrated bus architecture supports both single and redundant power supply configurations. This allows engineers to build high-availability systems that continue to protect machinery even during a primary power source failure.

FAQs

• How many vibration monitors can I install in this 14-slot rack?

  After installing the mandatory power supply and Rack Interface Module (RIM), you typically have 12 slots remaining. Since many 3500 modules feature four channels, one rack can monitor up to 48 individual vibration points.

• Does this part number include the rack ears for mounting?

  Yes. The "02" mounting option includes the integrated hardware necessary to secure the 19-inch rack to standard EIA rails in your instrument cabinet.

• What is the benefit of the CEE compliance option?

  The CEE suffix indicates the rack meets specific European safety and electromagnetic requirements. This ensures the hardware integrates seamlessly into projects requiring CE marking and European industrial certification.

• Is this a genuine Bently Nevada product?

  We guarantee that every 3500/05-01-02-00-00-01 is 100% brand new and original. Each unit ships in original factory packaging and includes a full 1-year comprehensive warranty.
