3500 Series | Bently Nevada 3500/05-01-03-00-00-00 System Rack

Product Overview

The Bently Nevada 3500/05-01-03-00-00-00 represents the core structural framework of the 3500 Machinery Protection System. This 19-inch EIA system rack houses all monitoring modules, power supplies, and gateways, providing the essential backplane communication required for continuous machinery health assessment. It enables high-speed data transfer between modules, ensuring instantaneous trip logic execution and diagnostic data availability. We supply this rack in 100% brand new, original condition to guarantee maximum uptime for critical rotating assets.

Part Number Breakdown: 3500/05-01-03-00-00-00

• 3500/05: System Rack Series

• -01: 19-inch Rack Mount Option (Standard EIA Rack)

• -03: 14-Slot Rack (Maximum module capacity)

• -00: No Agency Approvals (Standard non-hazardous area)

• -00: No Display Option

• -00: No Agency Approvals

Technical Specifications

• Manufacturer: Bently Nevada (Baker Hughes)

• Rack Size: 19-inch EIA standard infrastructure

• Slot Capacity: 14 available positions for monitor and communication modules

• Series: Bently Nevada 3500

• Mounting Type: Front-access rack mounting

• Backplane: High-speed digital bus for inter-module communication

• Condition: 100% Brand New, Factory Original

• Availability: In Stock for immediate global dispatch

Engineering Advantages

The 3500/05-01-03-00-00-00 chassis facilitates high-density monitoring in demanding industrial environments through superior design:

• Maximum Slot Density: The 14-slot configuration allows engineers to monitor entire machinery trains—including turbines, compressors, and pumps—from a single unified chassis. This reduces cabinet space requirements and simplifies system architecture.

• EMI/RFI Shielding: The rack backplane incorporates heavy-duty shielding to block electromagnetic interference. This design prevents signal corruption in high-voltage environments, ensuring that protection logic remains stable and accurate.

• Simplified Maintenance: The front-loading design enables rapid module replacement. Maintenance teams can swap monitor cards without disturbing the rear field wiring, significantly reducing Mean Time to Repair (MTTR).

• Structural Integrity: Bently Nevada constructs the 3500/05 rack to withstand the constant high-frequency vibration common in industrial turbine decks. This prevents mechanical fatigue of the backplane connectors and ensures long-term electrical contact.

FAQs

• Does this rack include the power supply or monitor modules?

  No. The 3500/05-01-03-00-00-00 provides the physical chassis and backplane. You must purchase the 3500/15 power supplies and individual monitoring cards separately based on your specific application needs.

• Can I install this rack in a standard 19-inch server cabinet?

  Yes. The "-01" option designates a standard 19-inch EIA rack mount configuration. It features standard mounting ears that align with industrial server racks and control room cabinets.

• What is the benefit of the 14-slot version over the 7-slot version?

  The 14-slot rack provides the highest level of scalability. It allows for redundant power supplies, multiple communication gateways, and a full suite of vibration and thrust monitors within one integrated enclosure.

• Is this a genuine Bently Nevada product?

  We guarantee that every 3500/05-01-03-00-00-00 is 100% brand new and original. Each unit ships in its original manufacturer packaging and includes a comprehensive 1-year warranty.
