5466-411 | Woodward Micronet Ethernet Module

Woodward 5466-411 NetCon/MicroNet Ethernet Communication Module (RJ45)

The Woodward 5466-411 is an Ethernet communication module with RJ45 interface for NetCon 5000 and MicroNet digital control systems. It provides high-speed network connectivity for remote monitoring, configuration, and integration with plant-wide DCS and SCADA networks.

Key Specifications

• Part Number: 5466-411
• Product Type: Ethernet Communication Module
• Series: NetCon 5000 / MicroNet
• Manufacturer: Woodward, Inc.
• Interface: RJ45 Ethernet port
• Protocols: Modbus TCP, Ethernet Global Data (EGD), OPC
• Data Rate: 10/100 Mbps auto-negotiation
• Compatibility: NetCon 5000 and MicroNet control platforms
• Operating Temperature: 0°C to 60°C
• Storage Temperature: -40°C to 85°C
• Humidity: 5% to 95% non-condensing
• Mounting: Chassis slot installation

Features & Benefits

1. High-Speed Network Access: RJ45 interface enables 10/100 Mbps communication for real-time data exchange.
2. Multi-Protocol Support: Modbus TCP, EGD, and OPC compatibility ensures broad DCS/SCADA integration.
3. Remote Diagnostics: Enables off-site monitoring and troubleshooting, reducing maintenance costs.
4. Plug-and-Play Integration: Auto-detected by NetCon/MicroNet chassis upon insertion.

Applications

• Remote turbine monitoring and control
• Plant-wide DCS integration
• SCADA data acquisition
• Condition monitoring and predictive maintenance

FAQ

Q: Does the 5466-411 support fiber optic Ethernet?
A: No. The 5466-411 uses copper RJ45. For fiber optic communication, use Woodward fiber transceiver modules (e.g., 5464-473).

Q: Can I use this module in a MicroNet TMR system?
A: Yes, the 5466-411 is compatible with MicroNet platforms. Verify TMR Ethernet redundancy requirements in your system manual.

Installation Guide

1. Install 5466-411 into an available NetCon/MicroNet chassis slot.
2. Connect CAT5e or CAT6 Ethernet cable to the RJ45 port.
3. Configure IP address and subnet via Woodward Toolkit software.
4. Verify link status LED and network connectivity.
5. Test Modbus TCP or EGD communication with host DCS.

Selection Tips

• Network Topology: Confirm your plant network uses standard Ethernet (RJ45) vs. fiber before ordering.
• Protocol: Verify DCS supports Modbus TCP or EGD for seamless integration.
