5X00226G03 | Westinghouse Ovation | I/O Interface Controller

Overview

The Westinghouse 5X00226G03 is an I/O Interface Controller for the Ovation distributed control system. It converts 180–265 VAC bulk power to a regulated 24 VDC output for powering I/O modules and field devices.

Technical Specifications

• Manufacturer: Westinghouse (Emerson)
• Model: 5X00226G03
• Type: I/O Interface Controller
• Input Voltage: 180–265 VAC
• Output Voltage: 24 VDC
• Output Current: 25 A
• Rated Power: 600 W
• Efficiency: 95%
• Dimensions: 230 × 150 × 70 mm

Environmental Ratings

• Operating Temperature: −40 °C to +70 °C
• Relative Humidity: 5%–95% non-condensing

Key Features

• 180–265 VAC wide-range input for global power compatibility
• 24 VDC 25 A regulated output for high-capacity I/O power
• 600 W continuous power delivery
• Compact design for control cabinet integration

FAQ

Q: What is the output capacity?
A: The 5X00226G03 delivers 24 VDC at 25 A, rated for 600 W continuous operation.

Q: Can this be used in redundant power architectures?
A: Verify Ovation chassis redundancy options; this module provides single-source DC power.

Installation Guidelines

1. Mount the module in the designated Ovation power rack slot.
2. Connect 180–265 VAC bulk power to the input terminals.
3. Verify 24 VDC output before energizing downstream I/O modules.

Selection Tips

• Select 5X00226G03 when you need AC-to-DC power conversion for Ovation I/O subsystems.
• Confirm total I/O power draw does not exceed 600 W.
