ABB Bailey INFI 90 and Symphony DCS IPFAN12 Industrial Fan Unit

Product Overview

The ABB Bailey IPFAN12 is a Fan Assembly designed for the INFI 90 and Symphony DCS control system cabinets. It provides active cooling for Module Mounting Units (MMU) and power supplies, ensuring proper thermal management and preventing overheating of critical control electronics. The IPFAN12 is essential for maintaining system reliability in high-temperature or high-density installations.

Key Technical Specifications

• Product Type: Fan Assembly
• Series: ABB Bailey INFI 90 / Symphony
• Function: Cabinet cooling for MMU and power supplies
• Mounting: Cabinet or chassis-mounted
• Origin: Sweden / USA

Related Fan Models

• IPFAN11 — Fan Assembly
• IPFAN12 — Fan Assembly
• IPFAN14 — Fan Assembly

Key Features

• Active Cooling: Prevents overheating of control modules and power supplies
• Thermal Management: Maintains optimal operating temperature within control cabinets
• High Reliability: Industrial-grade fan design for continuous duty
• Easy Maintenance: Hot-swappable design for replacement without system shutdown

Applications

• INFI 90 cabinet cooling
• Symphony DCS thermal management
• Power supply heat dissipation
• High-density MMU installations

Installation Guide

1. Mount fan assembly in designated cabinet location
2. Connect power supply (typically 120/240 VAC or 24 VDC)
3. Verify airflow direction matches cooling requirements
4. Check fan operation and alarm contacts

FAQ

Q: What is the difference between IPFAN12 and IPFAN14?
A: They are different fan assembly models with varying airflow capacity and physical dimensions. Verify your cabinet requirements.

Q: Is IPFAN12 hot-swappable?
A: Yes, it is designed for replacement without system shutdown in most configurations.

Model Selection Tips

• IPFAN12 = Fan Assembly for INFI 90/Symphony cabinets
• Verify cabinet size and airflow requirements
• Check power supply voltage (AC vs. DC)
• For higher airflow, consider IPFAN14
