ABB Bailey IPSYS01 System Power Module

Product Overview

The ABB Bailey IPSYS01 is a System Power Module for the INFI 90 and Symphony DCS product families. It provides regulated DC power to all modules within the Module Mounting Unit (MMU), ensuring stable and reliable operation of the entire control system. The IPSYS01 is a critical component for system availability, converting incoming AC or DC power to the precise voltages required by INFI 90/Symphony control modules.

Key Technical Specifications

• Product Type: System Power Module
• Series: ABB Bailey INFI 90 / Symphony
• Function: System power supply and distribution
• Mounting: INFI 90/Symphony Module Mounting Unit (MMU)
• Origin: Sweden / USA

Key Features

• Regulated DC Output: Precise voltage regulation for all control modules
• System Power Distribution: Powers all modules within the MMU
• High Reliability: Industrial-grade design for continuous operation
• Fault Tolerance: Supports redundant power configurations
• Status Monitoring: Provides power status feedback to system diagnostics

Applications

• INFI 90 system power supply
• Symphony DCS power distribution
• MMU module power regulation
• Control system power backup integration

Installation Guide

1. Install IPSYS01 in dedicated MMU power slot
2. Connect incoming AC or DC power source
3. Verify output voltage levels with multimeter
4. Check power status indicators
5. Monitor power module temperature and load

FAQ

Q: What voltages does IPSYS01 provide?
A: Standard INFI 90/Symphony DC voltages (typically +5V, ±12V, +24V depending on module requirements).

Q: Can it be used in redundant power configurations?
A: Yes, it supports redundant power setups for high-availability applications.

Model Selection Tips

• IPSYS01 = System Power Module for INFI 90/Symphony
• Verify input power source (AC vs. DC) and voltage
• Confirm MMU power slot compatibility
• For field power distribution, consider IPFLD01/IPFLD24/IPFLD48
• For power monitoring, pair with IPMON01
