ABB HAC807A01 3BHE028767R0101 PC Board for PLC Control

Product Description

The ABB HAC807A01 (Part Number: 3BHE028767R0101) is a precision-engineered PC Board designed as an add-on module for PLC and machine control systems. Built with a multi-layer architecture, this board ensures stable performance and reliable signal integrity in demanding industrial automation environments.

Technical Specifications

• Part Number: 3BHE028767R0101

• Category: PLCs / Machine Control

• Subcategory: PC Board PLC / Add-On Board

• Weight: 0.15 lbs (0.068 kg)

• Dimensions:

• Length: 2.2 cm (0.87 in)

• Width: 12.4 cm (4.88 in)

• Height: 12.6 cm (4.96 in)

• Board Type: Multi-layer PCB

• Connector Type: 20-pin IDC

• PCB Thickness: 1.6 mm (0.063 in)

• Mounting Type: Through-hole

• Trace Width: 0.25 mm (10 mils)

• Solder Mask Color: Green

Key Features

• Compact design optimized for integration into PLC systems.

• Multi-layer construction for enhanced durability and electrical performance.

• Standardized 20-pin IDC connector for easy interfacing.

• Through-hole mounting ensures mechanical stability in industrial setups.

Application Scenarios

• Expansion of PLC control functionality in machine automation.

• Signal processing and communication within modular control systems.

• Suitable for environments requiring compact yet robust PCB solutions.

FAQ

Q: What type of connector does this board use?  A: The HAC807A01 uses a 20-pin IDC connector for reliable interfacing.

Q: Is this board suitable for high-vibration environments?  A: Yes, the through-hole mounting design provides mechanical stability, making it suitable for industrial applications.

Q: Can this board be used with non-ABB PLCs?  A: It is primarily designed for ABB PLC systems; compatibility with other brands may require additional interface adjustments.
