Allen Bradley 1783-BMS06TL Stratix 5700 Managed Ethernet Switch

Product Overview

The Allen Bradley 1783-BMS06TL functions as a high-performance, managed networking solution within the Stratix 5700 product line. This compact switch incorporates Cisco technology to provide a secure and scalable integration between the factory floor and the enterprise network. Featuring 6 Fast Ethernet ports and the specialized "Lite" firmware, this module handles essential management functions including VLANs, port security, and basic diagnostics. We supply this unit as 100% Brand New and Factory Original, offering a critical solution for maintaining industrial network architectures where the manufacturer has discontinued the model.

Technical Specifications

The 1783-BMS06TL utilizes ruggedized hardware to maintain wire-speed switching in harsh industrial environments:

Engineering Advantages

• Cisco-Powered Integration: The 1783-BMS06TL utilizes the Cisco IOS (Internetwork Operating System), allowing IT and OT professionals to use familiar tools for network management. This synergy simplifies the configuration of secure industrial zones and ensures seamless data flow between PLC systems and SCADA software.

• Optimized Lite Firmware: The "Lite" firmware version provides essential managed features without the complexity of full-tier software. It enables port mirroring for troubleshooting and VLAN tagging to segment industrial traffic, preventing broadcast storms from affecting critical control loops.

• Flexible DC Power Input: The switch operates across a wide 12V to 48V DC input range. This allows the 1783-BMS06TL to run directly off standard 24V DC control power or battery-backed 48V systems, ensuring network persistence even during localized power fluctuations.

• Rugged DIN Rail Mounting: The integrated DIN rail clip secures the switch against industrial vibration. Its vertical orientation maximizes airflow and fits into standard control cabinets, solving the problem of high-density networking in restricted enclosure spaces.

• Premature Failure Resistance: Industrial-grade components allow this switch to operate in temperatures and electromagnetic environments where commercial switches fail. The solid-state design eliminates internal fans, preventing dust accumulation and extending the hardware lifecycle in textile or wood processing facilities.

FAQs

• Is the 1783-BMS06TL 100% Brand New?

  Yes. We guarantee this switch is 100% Brand New and arrives in its original factory packaging. Each unit undergoes rigorous quality inspection to ensure the internal circuitry and port contacts meet original Allen Bradley specifications.

• What is the difference between "Lite" and "Full" firmware?

  "Lite" firmware provides core managed features like VLANs and basic security. If your application requires advanced Layer 3 routing or specialized Cisco features, you would typically look at the "Full" version. For most standard PLC-to-HMI communications, the Lite firmware in the 1783-BMS06TL is the cost-effective choice.

• Can I configure this switch through Studio 5000?

  Yes. The Stratix 5700 series supports Add-On Profiles (AOP). This allows you to configure and monitor the switch directly within your Logix Designer environment, treating the network switch as a native I/O device.

• What type of cabling do I need for the 6 ports?

  The 1783-BMS06TL features standard RJ45 ports. We recommend using shielded Cat5e or Cat6 industrial Ethernet cables to maintain signal integrity in high-EMI environments near motor drives and power contactors.
