Allen-Bradley 1783-BMS10CGN Stratix 5700 Managed Ethernet Switch

Product Overview

The Allen-Bradley 1783-BMS10CGN Stratix 5700 serves as a critical component in modern industrial automation architectures. This managed Ethernet switch delivers robust network infrastructure specifically designed for demanding manufacturing environments. Engineers utilize this device to establish secure, high-speed connections between controllers, drives, and HMIs. The unit supports advanced features like Network Address Translation (NAT) and CIP Sync, ensuring precise timing and secure data flow across the plant floor. We supply this product as 100% Brand New and in original packaging, guaranteeing full factory specifications and reliability for your latest system integration project.

Technical Specifications

Engineering Advantages

Flexible Connectivity for Converged Networks
The 1783-BMS10CGN integrates seamlessly into existing infrastructures through its versatile port configuration. You can connect legacy 10/100 Mbps devices using the eight dedicated copper ports while simultaneously linking high-bandwidth controllers via the two Gigabit combo ports. The SFP slots on the combo ports allow you to deploy fiber optic cabling, effectively eliminating electromagnetic interference (EMI) in electrically noisy environments.

Precision Timing and Synchronization
Motion control applications demand exact timing. This switch supports CIP Sync technology, which leverages IEEE 1588 to synchronize devices across the network. This capability reduces jitter and ensures that drives and actuators operate in perfect unison, directly improving product quality and machine throughput.

Simplified Power Redundancy
Industrial power supplies can fluctuate. The unit accepts a wide DC input range from 12V to 60V, covering standard 24V and 48V industrial buses. You can connect two separate power sources to the dual connectors, creating a redundant power setup that maintains network uptime even if one power supply fails.

FAQs

Q: Can I use fiber optic cables with the combo ports?
A: Yes. The two combo ports feature SFP (Small Form-factor Pluggable) slots. You can insert compatible SFP transceivers to utilize fiber optic connections for long-distance runs or high-noise immunity.

Q: Does this switch support network security features?
A: Absolutely. The 1783-BMS10CGN includes Network Address Translation (NAT). This feature allows you to segregate machine-level networks from the plant-wide network, enhancing security and managing IP address conflicts effectively.

Q: What is the power requirement for installation?
A: The switch operates on a DC voltage range of 12-60V. For installation, ensure your power supply can deliver sufficient current within this range. Using the dual power connectors is recommended for critical applications requiring redundancy.
