Allen-Bradley 1786-BNC ControlNet Coaxial Bable Connector Plug

Product Overview

The Allen-Bradley 1786-BNC serves as the critical termination component for ControlNet coaxial communication networks. This BNC plug ensures a secure, low-impedance connection between RG-6 Quad Shield (RG-6QS) cables and ControlNet taps or network interfaces. It facilitates high-speed deterministic data transfer across the plant floor by maintaining signal integrity at every junction. We supply this product as 100% Brand New and original factory hardware, ensuring your network infrastructure meets the official Rockwell Automation specifications for mission-critical uptime.

Technical Specifications

The 1786-BNC utilizes high-grade materials to meet the rigorous demands of industrial ControlNet (RG-6) media systems.

Engineering Advantages

• Optimized Signal Conductivity: The 1786-BNC features precision-machined contact surfaces that minimize signal attenuation. This prevents data packet loss and prevents "retries" in high-speed ControlNet loops where deterministic timing is vital.

• Shielding Integrity for RG-6QS: Specifically designed for Quad Shield cables, this connector provides 360-degree shielding coverage. This architecture blocks electromagnetic interference (EMI) and radio frequency interference (RFI) typical of heavy industrial environments near VFDs and motors.

• Streamlined Field Termination: The connector simplifies the cabling process. When used with standard industrial crimping tools, the 1786-BNC creates a gas-tight seal on the RG-6QS jacket, preventing oxidation and maintaining long-term electrical stability.

• Industrial Durability: Unlike standard consumer-grade BNC connectors, the 1786-BNC withstands the vibrations and mechanical stresses found in industrial cabinets. The twist-lock mechanism ensures the cable remains seated even during high-vibration machinery operation.

FAQs

• Is the 1786-BNC 100% Brand New?

  Yes. We supply only Brand New original Allen-Bradley connectors. Each unit arrives in factory-fresh condition to ensure optimal performance for your communication infrastructure.

• Does this connector work with standard RG-6 television cable?

  The 1786-BNC requires RG-6 Quad Shield (RG-6QS) cable for industrial ControlNet applications. While it may physically fit some standard RG-6 cables, using non-industrial media compromises the network's noise immunity and signal quality.

• What tools do I need for installation?

  You require a standard coaxial cable stripper and an industrial-grade crimping tool calibrated for RG-6QS BNC connectors. Proper stripping of the quad shielding is essential to ensure the connector grounds correctly to the cable braid.

• Can I use this for Video or CCTV applications?

  While this is a BNC connector, Allen-Bradley specifically optimizes the 1786-BNC for ControlNet communication protocols. We recommend utilizing this part only within industrial automation networks to maintain system certification and reliability.
