Allen Bradley 2198-H008-ERS Kinetix 5500 Servo Drive

Product Overview

The Allen Bradley 2198-H008-ERS belongs to the high-performance Kinetix 5500 servo drive family, specifically designed to streamline motion control systems through an innovative single-cable design. This drive provides precise velocity and position control for synchronized multi-axis applications. By supporting both single-phase and three-phase power inputs, it adapts to diverse global industrial power grids. We supply this module as a 100% Brand New, original factory-sealed unit, ensuring peak efficiency and full compliance with modern safety standards.

Technical Specifications

The 2198-H008-ERS balances a compact frame with high output capacity to drive a wide range of rotary and linear motors.

Engineering Advantages

• Integrated Motion over EtherNet/IP: This drive eliminates the need for a separate motion network. It utilizes standard Ethernet infrastructure to communicate directly with Logix controllers, reducing hardware costs and simplifying system architecture.

• Single-Cable Technology: The 2198-H008-ERS pairs with VP-Series motors to run power, feedback, and brake lines through a single cable. This advancement reduces wiring time by 50% and minimizes potential points of failure in high-flexion robotic applications.

• Space-Saving Zero-Stacking: The innovative "Zero-Stack" design allows engineers to mount multiple drives side-by-side with no gap. This feature significantly shrinks the control cabinet footprint, solving the pain point of limited floor space in modern manufacturing cells.

• Hardwired Safe Torque Off (STO): The "ERS" designation indicates integrated STO functionality. This hardware-based safety circuit prevents the drive from generating torque during an E-stop event without removing power from the entire drive, facilitating faster system restarts after safety interventions.

• Common DC Bus Capability: When installed in multi-axis configurations, the drive supports a shared DC bus. This allows the system to reuse energy generated by decelerating motors to power accelerating axes, drastically lowering overall energy consumption.

FAQs

• Does the 2198-H008-ERS arrive in the original box?

  Yes. We ship the 2198-H008-ERS in its 100% Brand New original Allen Bradley packaging, complete with factory seals and inspection documentation.

• Can I run this drive on a single-phase 230V AC supply?

  Yes, this model supports 230V single-phase input. However, you must de-rate the output capacity according to the official Kinetix 5500 selection guide to ensure stable operation under load.

• What is the difference between the -ERS and -ERS2 models?

  The -ERS model (this unit) features hardwired Safe Torque Off. The -ERS2 version supports Integrated Safety over EtherNet/IP. If your controller manages safety via the network (CIP Safety), you may require the ERS2; otherwise, the ERS is the standard for hardwired safety circuits.

• Does this drive require a separate external 24V DC supply?

  Yes. You must provide a 24V DC control power source to maintain the logic and communication functions of the drive, even when the high-voltage AC bus is disconnected for maintenance.
