Allen-Bradley 2711P-B7C15D7 PanelView Plus 700 Operator Terminal

Product Overview

The Allen-Bradley 2711P-B7C15D7 is a PanelView Plus 7 700 operator terminal featuring a 7-inch color display with keypad and touchscreen input, ControlNet communication, and DC power input. It combines the latest PanelView Plus 7 platform with deterministic network connectivity for advanced industrial HMI applications.

Key Specifications

• Product Family: PanelView Plus 7
• Display Size: 7 inches
• Display Type: Color TFT LCD, 18-bit color graphics
• Input Type: Keypad and Touchscreen
• Communication: ControlNet
• Power Input: DC (18–30V DC)
• Operating System: Windows CE 6.0 Standard
• Memory: 512 MB RAM, 512 MB nonvolatile memory (approx. 80 MB free user memory)
• Ethernet: 1 × RJ45 10/100 MB Auto-MDI/MDI-X
• USB: 1 USB 2.0 port (Type A)
• SD Card: 1 × SDHC slot
• Enclosure Rating: NEMA 12, 13, 4X; IP54, IP66
• Operating Temperature: 0–55 °C (32–131 °F)
• Certifications: C-UL-us, CE, RoHS, EAC

Features & Benefits

• PanelView Plus 7 Platform: Latest-generation HMI with improved performance and modern connectivity
• Dual Input Methods: Keypad and touchscreen provide flexible operator interaction for diverse conditions
• ControlNet Communication: Deterministic high-speed network for real-time control applications
• Ethernet Port: Additional 10/100 Mbps Ethernet for flexible network architecture
• Windows CE 6.0: Reliable embedded OS with standard features for most HMI needs
• SD Card Support: Easy application backup, restore, and data logging via SDHC card
• Robust Enclosure: IP66 front panel rating for demanding washdown environments

Applications

• Real-time process control HMI
• Machine operator stations
• Batch control interfaces
• Manufacturing line monitoring
• ControlLogix system visualization

Installation Guide

1. Panel Cutout: Prepare panel cutout per the PanelView Plus 7 700 installation template.
2. Mounting: Secure terminal using provided mounting hardware. Verify IP66 seal integrity.
3. Power Connection: Connect 24V DC (18–30V DC range) to the power input terminals.
4. ControlNet Setup: Connect ControlNet coaxial cable and configure node address.
5. Ethernet Configuration: Configure Ethernet port for additional network connectivity if required.
6. Software Loading: Use FactoryTalk View Studio for Machine Edition to develop and download HMI applications.

FAQ

Q: What is the difference between PanelView Plus 6 and Plus 7?
A: PanelView Plus 7 offers improved performance, modern connectivity options, and enhanced environmental ratings compared to Plus 6.

Q: Can this terminal run FactoryTalk ViewPoint?
A: Yes. PanelView Plus 7 supports FactoryTalk ViewPoint for remote web-based access to HMI displays.

Q: What is the maximum free user memory?
A: Approximately 80 MB of free user memory is available for HMI applications.

Selection Tips

• Verify ControlNet network infrastructure for deterministic communication
• Confirm 24V DC power availability
• Consider keypad + touch vs. touch-only based on operator environment
• Ensure FactoryTalk View Studio ME is available for application development
• Evaluate PanelView Plus 7 Performance models for more demanding applications
