Allen-Bradley H100-610 UE Pressure Switch Module

Product Description

The H100-610 is a precision-engineered pressure switch module from Allen-Bradley, designed for robust monitoring and control in industrial applications. It offers a wide adjustable setpoint range of 75–1000 PSI and is equipped with a single SPDT contact rated at 15A for 125V, 250V, and 480V AC.

Constructed for durability, the module features a NEMA 4X enclosure, ensuring resistance against dust, water, and harsh industrial environments. The pressure-sensing components include a 303 stainless steel piston and a Buna-N O-ring, paired with a 1/4" FNPT 303SS pressure connection for secure installation. Electrical connections are supported via a 1/2" FNPT and two 7/8" diameter knockouts. The internal adjustment mechanism allows fine-tuning of the pressure setpoint for precise control.

Technical Specifications

• Model: H100-610

• Product Type: Pressure Switch Module

• Setpoint Range: 75–1000 PSI

• Contact Type: 1 × SPDT

• Contact Rating: 15A @ 125/250/480 VAC

• Pressure Connection: 1/4" FNPT, 303 Stainless Steel

• Enclosure: NEMA 4X

• Materials: 303 Stainless Steel Piston, Buna-N O-Ring

• Electrical Connections: 1/2" FNPT + Two 7/8" Dia. Knockouts

• Adjustment: Internal Setpoint Adjustment

Features

• Wide adjustable pressure range suitable for varied applications

• Single SPDT contact compatible with multiple AC voltages

• Corrosion-resistant stainless steel construction

• NEMA 4X enclosure for harsh environments

• Internal adjustment for precise setpoint calibration

Application Scenarios

Ideal for hydraulic and pneumatic systems, industrial machinery, pumps, compressors, and process control where accurate pressure monitoring is required.

FAQs

Q: What is the maximum pressure range of the H100-610?
A: It can be set between 75 PSI and 1000 PSI.

Q: What type of contact does this switch use?
A: It uses one SPDT contact rated at 15A.

Q: Can it be used outdoors or in wet conditions?
A: Yes, the NEMA 4X enclosure provides protection against water and dust.
