Allen-Bradley PowerFlex 22-COMM-E EtherNet/IP Communication Adapter

Product Description

Allen-Bradley EtherNet/IP Adapter – Model: 22-COMM-E  The 22-COMM-E is a communication adapter designed for PowerFlex drives, enabling Ethernet/IP connectivity for industrial automation systems. It provides robust communication performance with multiple data rates, diagnostic indicators, and support for up to 30 TCP connections. Compact and reliable, this adapter integrates seamlessly with PowerFlex 4, 40, and 400 drives.

Technical Specifications

• Brand: Allen-Bradley

• Product Line: PowerFlex 40

• Model: 22-COMM-E

• Type: EtherNet/IP Communication Adapter

• Compatible Drives: PowerFlex 4, 40, 400

• Communication Port: One RJ45 connector

• Protocol: Ethernet/IP

• Supported Data Rates: 10 Mbps full/half duplex, 100 Mbps full/half duplex

• TCP Connections: Up to 30 simultaneous connections

• RPI (Requested Packet Interval): Minimum 5 ms

• Packet Rate: Up to 400 I/O packets per second (200 inbound, 200 outbound)

• Drive Power Consumption: 350 mA @ 5 VDC (supplied by host drive or DPI external kit)

• Status Indicators: 4 LEDs for diagnostics and communication status

• DSI Connector: 20-pin interface

• Cable Type: RJ-45 CAT compliant cable

• Operating Temperature: –10 to 50 °C (14 to 122 °F)

• Storage Temperature: –40 to 85 °C (–40 to 185 °F)

• Relative Humidity: 5–95% non-condensing

• Regulatory Compliance: UL508C, CAN/CSA C22.2 No. 14-M91, EN50178, EN61800-3

• Weight: 0.13 lbs (0.06 kg)

Application Scenarios

• Integration of PowerFlex drives into Ethernet/IP networks

• Machine control systems requiring high-speed communication

• Process automation with distributed I/O and drive connectivity

• Applications needing diagnostic visibility and multiple TCP connections

FAQ

Q: Which drives are compatible with the 22-COMM-E adapter?  A: It supports PowerFlex 4, PowerFlex 40, and PowerFlex 400 drives.

Q: What is the maximum number of TCP connections?  A: The adapter supports up to 30 TCP connections simultaneously.

Q: Does the module provide diagnostic indicators?  A: Yes, it includes 4 LEDs for communication and status monitoring.
