Allen-Bradley 80026-096-01-R Power Supply Module

Description

The Allen-Bradley 80026-096-01-R is a robust DC/DC power supply module designed for industrial control applications. Engineered for reliability in demanding environments, this unit provides a stable 24 VDC output to support various automation components, sensors, and control logic systems. It is often utilized within PowerFlex drive systems or associated control cabinets where consistent DC power is critical for operational uptime.

Features

• Reliable 24 VDC output voltage for sensitive control electronics.
• High-efficiency power conversion for industrial automation demands.
• Designed for standard AC input ranges (120/240V AC).
• Continuous current output capability to support multiple I/O or control loads.
• Compact, ruggedized form factor suitable for panel mounting.

Technical Specifications

Installation Guidelines

• Ensure the power supply is installed in a clean, dry, and well-ventilated enclosure to prevent overheating.
• Verify that the input AC voltage matches the module specifications before applying power.
• Use appropriate wire gauges for input and output connections to minimize voltage drop and heat generation.
• Ensure a solid chassis ground connection to mitigate EMI/RFI interference.
• Always disconnect all power sources before attempting to install, remove, or perform maintenance on the module.
• Maintain adequate clearance around the unit to allow for natural convection cooling.

FAQ

Is this power supply compatible with older Allen-Bradley control systems?

The 80026-096-01-R is a classic component often used as a direct replacement or spare for legacy Allen-Bradley drive and control systems. Please verify your specific system manual or the spare model number 80026-227-05 to ensure full compatibility with your existing hardware configuration.

What is the primary function of this module?

This module serves as a dedicated DC power supply, converting standard AC line voltage into a regulated 24 VDC supply required for operating industrial control logic, communication modules, and auxiliary field devices.
