Bently Nevada 146031-01 3500/22M Transient Data Interface I/O Module

Overview
The 146031-01 Transient Data Interface (TDI) I/O Module from Bently Nevada serves as a network bridge within the 3500/22M system, enabling communication between monitoring modules and software platforms such as System 1 Condition Monitoring and 3500 System Configuration. This module supports both 10Base-T and 100Base-TX Ethernet standards for high-speed data transfer.

Technical Specifications

• Model: 146031-01

• Product Type: Transient Data Interface (TDI) I/O Module

• Dimensions: 3 x 12 x 25 cm

• Weight: 0.45 kg

• Power Supply: 12 V DC, 1 A (external)

• Ethernet Standards: IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX

• Media Type: UTP Category 3, 4, 5

• Data Transfer Rate: 10 Mbps, 100 Mbps

• Auto-Negotiation: Yes

• Auto-MDIX: Yes

• Ports: 1 RJ-45

• LED Indicators: Link/Activity, Speed

Features

• Provides seamless integration with 3500/22M monitoring systems

• Supports high-speed Ethernet communication for transient data

• Compact design for easy rack installation

• LED indicators provide real-time status of link and network speed

Applications

• Real-time data collection and transmission within 3500/22M systems

• Integration with System 1 Condition Monitoring and Diagnostics software

• Networking interface for machinery condition monitoring and configuration

FAQ
Q: Can this module be used with other 3500 series modules?
A: It is specifically designed for the 3500/22M system for optimal communication and software compatibility.

Q: Does it support automatic cable configuration?
A: Yes, Auto-MDIX is supported to automatically detect straight-through or crossover cables.
