Bently Nevada 3300/16-15-01-03-00-00-02 Dual Channel Vibration Monitor Module

Overview

The Bently Nevada 3300/16-15-01-03-00-00-02 Dual Channel Vibration Monitor Module is a high-performance unit from GE / Bently Nevada, designed for continuous vibration and displacement monitoring of rotating machinery. It provides two independent measurement channels to detect imbalance, misalignment, or bearing faults, ensuring reliable equipment protection and efficient condition-based maintenance.

This module forms part of the 3300 Series Machinery Protection System and is built for seamless integration with existing Proximitor® and proximity probe systems. Its rugged design and stable output performance make it ideal for critical applications in industrial environments requiring precise vibration analysis.

Technical Specifications

• Model Number: 3300/16-15-01-03-00-00-02

• Brand / Manufacturer: GE / Bently Nevada

• Product Type: Dual Channel Vibration Monitor Module

• System Compatibility: Bently Nevada 3300 Series

• Measurement Channels: 2 (vibration and displacement)

• Input Type: Proximitor® proximity probe systems

• Input Sensitivity: 200 mV/mil

• Full-Scale Range: 0–10 mils peak-to-peak

• Frequency Response: 10 Hz to 1 kHz

• Output Signal: 4–20 mA proportional to vibration amplitude

• Alarm Relays: Configurable alert and danger levels

• Input Voltage: 24 VDC nominal

• Operating Temperature: -40°C to +85°C

• Dimensions: 2.5 cm × 2.0 cm × 2.3 cm

• Weight: 1.02 kg

• Material: Stainless steel housing

• Country of Origin: USA

• Compliance: Meets API 670 and ISO 10816 vibration monitoring standards

Key Features

• Dual-Channel Monitoring: Measures two independent parameters—vibration and shaft displacement—for precise diagnostics.

• High Accuracy: Detects small vibration changes for early fault detection and predictive maintenance.

• Robust Construction: Industrial-grade stainless steel enclosure for long-term durability.

• System Integration: Designed for compatibility with Bently Nevada 3300 racks and Proximitor® systems.

• Stable Output: 4–20 mA analog signal ensures reliable interface with PLC and DCS systems.

• Wide Environmental Tolerance: Operates in extreme temperatures and high-vibration environments.

Application Scenarios

The Bently Nevada 3300/16-15-01-03-00-00-02 is widely used in:

• Turbines (steam and gas)

• Compressors and blowers

• Pumps and fans

• Electric motors and generators

• Power generation, oil refining, and petrochemical facilities

Its precise dual-channel configuration supports simultaneous monitoring of radial vibration and shaft position, providing essential data for condition monitoring and fault prevention systems.

FAQ

Q1: Is this module compatible with older 3300 systems?
Yes, it can be used with existing Bently Nevada 3300 racks and monitoring configurations without hardware modification.

Q2: What type of sensors can be connected?
It supports 3300 and 7200 series Proximitor® proximity probe systems with 200 mV/mil output.

Q3: How is it different from the 3300/16-14 model?
The 3300/16-15 version includes enhanced analog output stability and a wider operating temperature range, improving performance in demanding applications.
