Bently Nevada 3500/65 172103-01 RTD/Isolated Tip TC Input Module

Overview:
The Bently Nevada 3500/65 172103-01 module provides high-precision input processing for RTDs and isolated tip thermocouples (TCs) within the 3500/65 Temperature Monitoring system. It evaluates signals against configurable alarm thresholds and supports redundant configurations for reliable operation in critical industrial applications.

Specifications:

• Manufacturer: Bently Nevada

• Model: 3500/65 172103-01

• Product Type: RTD/Isolated Tip Thermocouple I/O Module

• Series: 3500

• Availability: In stock

• Dimensions: 241.3 mm × 24.4 mm × 99.1 mm

• Weight: 0.45 kg

• Country of Manufacture: USA

Features:

• Channel Configuration: Supports 16 independent temperature channels for multi-point monitoring.

• Input Compatibility: Accepts 3-wire and 4-wire RTDs as well as isolated tip thermocouples.

• Configuration: Programmed via 3500 Rack Configuration Software, allowing flexible combinations of TC and RTD inputs.

• Alarm Setpoints: Each input is evaluated against user-defined thresholds for process protection.

• Redundancy: Designed for Triple Modular Redundant (TMR) installation; uses dual voting mechanisms to mitigate single-point failures and ensure continuous operation.

Applications:
Ideal for industrial machinery temperature monitoring, including turbines, compressors, and pumps in oil, gas, and power generation facilities.

FAQ:
Q: Can this module handle mixed RTD and TC inputs simultaneously?
A: Yes, the 3500/65 172103-01 supports flexible combinations of RTD and isolated tip TC signals.

Q: What is the purpose of the TMR configuration?
A: Triple Modular Redundancy ensures operational reliability and protects against single-point failures in critical systems.
