Bently Nevada 3500/94 145988-01 VGA Display Module | 3500 Series

Product Overview

The Bently Nevada 3500/94 145988-01 functions as the primary visual interface for the 3500 Machinery Protection System. This VGA Display Module extracts real-time measurement data directly from the rack backplane and projects it onto a standard color VGA monitor. It supports advanced Touch Screen technology, allowing operators to navigate machinery status, viewing bar graphs, event lists, and alarm data directly at the rack location. We supply this module as 100% brand new, original factory equipment to ensure critical data visualization for your plant personnel.

Part Number Breakdown: 3500/94

• 3500/94: Main VGA Display Module Series.

• 145988-01: Specific High-Performance Main Module and I/O Card configuration.

Technical Specifications

• Manufacturer: Bently Nevada (Baker Hughes)

• Module Type: VGA Display Interface

• Display Compatibility: Standard Color VGA Monitors

• Input Technology: Supports Touch Screen Integration

• Maximum Cable Distance: 10 meters (33 feet) from the rack

• Module Weight: 0.55 kg

• Dimensions: 24.3 cm x 4.6 cm x 15.5 cm

• System Series: Bently Nevada 3500

• Condition: 100% Brand New Original

Engineering Advantages

The 3500/94 145988-01 optimizes local machinery monitoring through several specialized engineering features:

• Real-Time Data Visualization: This module eliminates the need for a separate computer to view rack data. It drives a local monitor to show instantaneous vibration levels and system alerts, providing immediate feedback during machine startup or troubleshooting.

• Extended Display Mounting: The 145988-01 allows for monitor placement up to 10 meters away from the actual 3500 rack. This flexibility enables engineers to mount the display at eye level or on an external cabinet door while keeping the core protection rack securely housed inside.

• Touch Screen Integration: By supporting touch technology, this module removes the requirement for external keyboards or mice in harsh industrial environments. Operators interact directly with the display, reducing the footprint of the monitoring station.

• Seamless Rack Integration: The module fits into any full-height slot within the 3500 rack. It automatically identifies all installed monitors in the system, populating the display with relevant data without complex manual programming.

FAQs

• Does the 145988-01 include the monitor?

  The part number 145988-01 covers the Main VGA Display Module and its corresponding I/O card. While it interfaces with a standard VGA monitor, the monitor itself typically requires a separate purchase based on your specific environmental mounting requirements.

• What happens if the display cable exceeds 10 meters?

  Standard VGA signals degrade beyond the 10-meter (33-foot) limit. For installations requiring greater distances, you must utilize high-quality shielded cabling or active VGA extenders to maintain signal clarity and touch screen responsiveness.

• Can I use this module for rack configuration?

  The 3500/94 serves as a display tool for viewing measurement data and statuses. To change rack configurations or set alarm setpoints, you must still utilize the 3500 Rack Configuration Software via the Rack Interface Module (RIM).

• Is this a genuine Bently Nevada part?

  Yes. We guarantee that every 3500/94 145988-01 we ship is 100% brand new and original. Each unit arrives in its original factory-sealed packaging and includes a full 1-year warranty.
