Bently Nevada 3500 Series System Rack | 3500/05-01-02-00-00-00

Product Overview

The Bently Nevada 3500/05-01-02-00-00-00 provides the critical physical and electrical infrastructure for the 3500 Machinery Protection System. This 7-slot "Mini-Rack" configuration offers a compact alternative to full-sized chassis, making it the ideal choice for smaller machinery trains or remote monitoring applications where cabinet space is limited. It houses all necessary monitor modules and power supplies while facilitating high-speed data exchange via the internal backplane. We supply this rack in 100% brand new, original condition to ensure the reliability of your machine protection assets.

Part Number Breakdown: 3500/05-01-02-00-00-00

• 3500/05: System Rack Main Series.

• -01: 19-inch Rack Mount Option (Mounts on standard EIA rails).

• -02: 7-Slot Mini-Rack (Compact 12-inch width chassis).

• -00: No Agency Approvals (Standard non-hazardous area configuration).

• -00: No Display Option.

• -00: No Agency Approvals.

Technical Specifications

• Manufacturer: Bently Nevada (Baker Hughes)

• Chassis Type: 7-Slot Mini-Rack

• Mounting Standard: 19-inch EIA Rack Mount (using specific adapters/brackets)

• Slot Allocation: 7 available slots for power supplies, interface modules, and monitors

• Backplane Interface: High-speed digital bus for synchronized data processing

• Power Distribution: Integrated busbars for centralized DC power delivery to all modules

• Condition: 100% Brand New, Factory Original

• Warranty: 1 Year

Engineering Advantages

The 3500/05-01-02-00-00-00 optimizes machinery protection through its specialized compact design:

• Footprint Optimization: The 7-slot "Mini-Rack" occupies significantly less horizontal space than the standard 14-slot version. This allows engineers to install comprehensive vibration and thrust monitoring in small-scale enclosures or crowded control rooms without sacrificing system performance.

• Scalable Architecture: Despite its smaller size, this rack uses the same backplane technology as the full-size 3500 racks. It supports redundant power supplies and high-speed communication gateways, ensuring no compromise on safety or data availability.

• Advanced Noise Rejection: The backplane architecture incorporates heavy-duty shielding to block Electromagnetic Interference (EMI) and Radio Frequency Interference (RFI). This ensures that low-level sensor signals remain clean and accurate even in high-voltage industrial environments.

• Simplified Installation: The 19-inch rack mount ears facilitate quick mounting into standard industrial cabinets. The front-loading design allows for rapid module insertion and removal, significantly reducing labor time during system commissioning or maintenance.

FAQs

• How many monitor modules can this 7-slot rack hold?

  Typically, the rack reserves two slots for the power supply and the Rack Interface Module (RIM). This leaves five slots available for individual monitoring modules (such as vibration, position, or temperature cards).

• Is this rack compatible with the same modules as the 14-slot rack?

  Yes. All Bently Nevada 3500 series modules are universal. You can use the same monitor cards, power supplies, and gateways in both the 7-slot and 14-slot rack versions.

• Does this rack support redundant power?

  Yes. The 7-slot rack supports the installation of two 3500/15 power supplies to provide redundant power paths, ensuring the system continues to operate if one power source fails.

• How do you guarantee the product is "Brand New"?

  We source only genuine, factory-original Bently Nevada equipment. Every 3500/05-01-02-00-00-00 arrives in its original manufacturer packaging with the factory seal intact, backed by a full 1-year warranty.
