Schneider Electric BMXDDO1602 Modicon X80 Discrete Output Module — 16-Channel, 24VDC Positive Logic, 0.5A

The BMXDDO1602 is a 16-channel discrete output module for Schneider Electric's Modicon X80 automation platform. It provides positive logic (source type) transistor outputs at 24 VDC, with each channel capable of switching up to 0.5 A and the entire module supporting a maximum of 10 A. The module features fast 1.2 ms response time, integrated overload and short-circuit protection, and comprehensive LED diagnostics for reliable industrial control of actuators, solenoid valves, and relays.

Key Specifications

• Manufacturer: Schneider Electric
• Series: Modicon X80 (M340 / M580)
• Type: Discrete Output Module, Transistor, Positive Logic
• Channels: 16 per IEC 61131-2
• Output Logic: Positive (source type)
• Output Voltage: 24 VDC (19–30 VDC range)
• Current per Channel: 0.5 A (rated); 0.625 A max
• Maximum Current per Module: 10 A
• Response Time: 1.2 ms (0→1 and 1→0)
• Maximum Voltage Drop: < 1.2 V at state 1
• Maximum Leakage Current: 0.5 mA at state 0
• Maximum Tungsten Load: 6 W
• Load Impedance: > 48 Ω
• Paralleling of Outputs: Yes, 2 channels maximum
• Switching Frequency: 0.5/LI² Hz
• Output Overload Protection: Electronic circuit breaker (1.5 In < Id < 2 In) with current limiting
• Output Short-Circuit Protection: 2 A external fuse
• Output Overvoltage Protection: TVS transil diode
• Reverse Polarity Protection: Reverse mounted diode
• Power Dissipation: 4 W
• Typical Current Consumption: 79 mA at 3.3 VDC
• Dielectric Strength: 1500 V AC at 50/60 Hz, 1 minute (output/ground and output/internal logic)
• Insulation Resistance: > 10 MΩ at 500 V DC
• LED Indicators: 1 green (RUN — module operating); 1 green per channel (channel diagnostic); 1 red (ERR — module error); 1 red (I/O)
• IP Rating: IP20
• Operating Temperature: 0°C to 60°C
• Storage Temperature: -40°C to 85°C
• Relative Humidity: 5–95% at 55°C, non-condensing
• Vibration Resistance: 3 gn
• Shock Resistance: 30 gn
• Operating Altitude: 0–2000 m; 2000–5000 m with derating
• Terminal Block: 20-way removable terminal block
• Mounting: DIN rail (X80 backplane slot)
• Dimensions: 11.0 cm (W) × 5.6 cm (H) × 12.0 cm (D) [Electrihub]
• Weight: 0.12 kg
• MTBF: 410,000 hours
• EAN Code: 3595863910469
• Carbon Footprint: 34 kg CO₂ eq. (total lifecycle)
• Certifications: CE, CSA, UL, RCM, Merchant Navy, EAC
• Standards: EN/IEC 61131-2, EN/IEC 61010-2-201, UL 61010-2-201, CSA C22.2 No 61010-2-201, 2014/35/EU (LVD), 2014/30/EU (EMC)
• Status: Active / In production

Architecture & Functionality

• Positive Logic (Source Type): Output sources current to the load when energized; load connected between output and common/ground
• Solid-State Transistor Outputs: No moving parts, high reliability, fast switching, long operational lifespan
• Per-Channel Diagnostics: Individual green LED for each channel indicates output state and diagnostic status
• Module Diagnostics: RUN (green), ERR (red), and I/O (red) LEDs provide comprehensive module health indication
• Electronic Overload Protection: Built-in current limiting prevents damage from overload conditions (1.5× to 2× rated current)
• Removable Terminal Block: 20-way terminal block allows pre-wiring and quick module replacement without disturbing field wiring
• Green Premium Product: Schneider Electric sustainability commitment — recycled cardboard packaging (min 70%), repair services available

Installation Guide

1. Install the BMXDDO1602 into a standard I/O slot on the Modicon X80 backplane (M340 or M580 rack).
2. Connect the 20-way removable terminal block to the module front.
3. Wire 16 output channels to field devices (actuators, solenoids, relays) observing positive logic polarity.
4. Connect 24 VDC power to the module via the terminal block.
5. Install 2 A external fuses per channel if required by your application.
6. Ensure load impedance > 48 Ω per channel.
7. Power on and verify RUN LED (green) illuminates; check per-channel green LEDs for active outputs.
8. Monitor ERR LED (red) for overload, short-circuit, or module fault conditions.

FAQ

Q: Is BMXDDO1602 relay or transistor output?
A: Transistor (solid-state) output. Some third-party sources incorrectly describe it as relay output. The BMXDDO1602 uses transistor technology for fast switching and high reliability. For relay outputs, use BMXDRA1605 or BMXDRC0805.

Q: Is BMXDDO1602 source or sink type?
A: Source type (positive logic). The module sources current to the load when the output is energized. For sink type (negative logic), use BMXDDO1602H or other sink variants.

Q: What is the difference between BMXDDO1602 and BMXDDO1602H?
A: BMXDDO1602 is the standard version. BMXDDO1602H is the conformal coated version for harsh environments (moisture/salt spray/mildew resistant). Both have identical electrical specifications.

Q: What is the difference between BMXDDO1602 and BMXDDO1612?
A: BMXDDO1602 has 0.5 A per channel (10 A module max). BMXDDO1612 has 0.1 A per channel (1.6 A module max) with faster 0.1 ms response time for high-speed applications.

Q: Can I parallel outputs for higher current?
A: Yes, up to 2 channels maximum. Paralleling two channels provides up to 1 A combined current. Do not exceed module maximum of 10 A.

Q: Is BMXDDO1602 compatible with M580?
A: Yes. The BMXDDO1602 is part of the Modicon X80 platform and is compatible with both M340 PAC and M580 ePAC systems using the X80 backplane.

Q: What is the maximum inrush current?
A: The module supports electronic overload protection with current limiting at 1.5× to 2× rated current (0.75–1 A per channel). For higher inrush loads, consider relay output modules.

Selection Tips

• X80, 16-channel, 24VDC, 0.5A, positive logic, transistor: BMXDDO1602
• X80, 16-channel, 24VDC, 0.5A, positive logic, conformal coated: BMXDDO1602H
• X80, 16-channel, 24VDC, 0.1A, positive logic, fast (0.1ms): BMXDDO1612
• X80, 16-channel, 24VDC, relay output: BMXDRA1605
• X80, 8-channel, 24VDC, relay output: BMXDRA0815
• Always verify: Output type (transistor vs relay), logic type (source vs sink), current requirements, and environmental conditions before ordering
• Order compatible terminal block: BMXFTB2010 (20-way screw terminal) or BMXFTB2020 (20-way spring terminal)
