CP133E-64-S3 | Yokogawa DCS Processor Module 30kHz Output

Yokogawa CP133E-64-S3 CENTUM CS Processor Controller Module

The CP133E-64-S3 (Model: CP133E-64 S3) is a high-performance processor module designed for the Yokogawa CENTUM CS Distributed Control System (DCS). This module serves as the primary controller for Field Control Stations, combining a 32-bit CPU with advanced memory management to execute complex control strategies and sequence logic. The CP133E-64-S3 is specifically engineered for high-availability industrial environments, providing deterministic processing and multi-protocol communication capabilities required for refining, power generation, and chemical process automation.

Detailed Technical Specifications

The following specifications define the hardware capabilities of the CP133E-64-S3 (Model: CP133E-64 S3) controller module.

• Manufacturer: Yokogawa Electric Corporation (Japan)

• Model Identification: CP133E-64-S3

• Processor Architecture: 32-bit High-speed CPU

• Memory Capacity: 64K words standard (Instruction/Data storage)

• I/O Capacity: Supports up to 256 physical I/O points

• System Compatibility: Yokogawa CENTUM CS Series

• Communication Interfaces: RS-232, RS-422, and RS-485

• Supported Protocols: Modbus (RTU/TCP), Profibus-DP, DeviceNet, and Yokogawa V-net

• Input Power Options: 24 V DC (Standard) or 220 V AC (S3 Variant specific)

• High-Speed Output: Supports frequencies up to 30 kHz

• Operating Temperature: –10°C to +55°C

• Dimensions: 66 mm × 49 mm × 125 mm

• Weight: 0.45 kg (0.99 lbs)

• Isolation Protection: Built-in EMI/RFI shielding for harsh environments
