F 6202 | HIMA F6202 Safety-Related Controller Module

Overview

The HIMA F 6202 is a Safety-Related Controller Module (CPU) for HIMA HIQuad safety systems. It executes safety logic, processes inputs, and controls outputs for safety instrumented systems.

Technical Specifications

• Manufacturer: HIMA
• Model: F 6202
• Type: Safety-Related Controller Module (CPU)
• Part Number: 981620202
• Supply Voltage: 5 VDC (via backplane)
• Power Consumption: 3 W
• Dimensions: 216 × 130 × 30 mm
• Weight: 1.36 kg
• Operating Temperature: 0 °C to +60 °C
• Storage Temperature: −40 °C to +85 °C
• Humidity: 5%–95% RH non-condensing

Environmental & Safety Ratings

• Safety Certification: SIL 3 (IEC 61508)
• Redundancy Support: 1oo2, 2oo3 configurations
• Protection Class: IP20 (rack mounted)

Key Features

• High-performance CPU for complex safety logic execution
• Triple modular redundancy (TMR) 2oo3 architecture
• Built-in self-test and continuous fault monitoring
• Hot-swappable design for online replacement
• Galvanic isolation across potential-free relay interfaces

FAQ

Q: Can F 6202 be replaced while the system is running?
A: Yes, the module is hot-swappable, allowing replacement during live operations without disrupting safety logic execution.

Q: What redundancy configurations are supported?
A: The processor supports both dual 1oo2 and triple modular 2oo3 configurations.

Installation Guidelines

1. Insert the module vertically into the allocated chassis slot guide rails.
2. Ensure PC board connectors align cleanly with backplane receiving pins.
3. Tighten faceplate retention fasteners to ground the front bracket.
4. Route communication bus wiring inside closed layout trays.

Selection Tips

• Order F 6202 as the primary CPU for HIQuad safety instrumented systems.
• Configure redundancy (1oo2 or 2oo3) via ELOP II Factory software.
