GE Fanuc VersaMax IC200CPU002 | Central Processing Unit

Product Description

The GE Fanuc VersaMax IC200CPU002 is a central processing unit module designed for reliable control in VersaMax PLC systems. It provides expanded memory capacity, dual serial communication ports, and a battery-backed real-time clock, making it a versatile solution for industrial automation. With support for multiple programming languages and robust digital I/O handling, this CPU ensures efficient execution of complex logic operations.

Technical Specifications

• Manufacturer: Emerson Automation (formerly GE Fanuc)

• Model / Part Number: IC200CPU002

• Product Line: VersaMax

• Product Type: CPU Module

• Weight: 0.25 lbs (0.11 kg)

• User Memory: 42 KB configurable for programs, registers, and I/O data

• Memory Storage: Non-volatile flash memory and battery-backed RAM

• Digital Inputs: 2048 points

• Digital Outputs: 2048 points

• Programming Languages Supported: Ladder Diagram, Instruction List

• Floating Point Math: Supported

• Communication Ports:

• RS-232 (1 port)

• RS-485 (1 port)

• Supported Protocols: SNP Slave, Modbus RTU Slave, Serial I/O

• Real-Time Clock (RTC): Battery-backed, 5-year battery life

• Accuracy: 0.01% overall, 0.0023% at 30 °C

• Run/Stop Switch: Manual control for CPU operation

• Mounting Options: DIN rail, vertical or horizontal orientation

• Power Supply: 5 VDC

• Backplane Current Consumption: 140 mA at 5 VDC

• Indicators: LED status indicators for system monitoring

Application Scenarios

The IC200CPU002 is ideal for mid-range automation systems requiring expanded memory and reliable communication. It is commonly used in machine control, process automation, and distributed I/O networks where precise timing and robust protocol support are essential.

FAQ

Q: How much user memory does the IC200CPU002 provide?  A: 42 KB of configurable memory for programs, registers, and I/O data.

Q: What communication protocols are supported?  A: SNP Slave, Modbus RTU Slave, and Serial I/O.

Q: How accurate is the real-time clock?  A: ±0.01% overall accuracy, with ±0.0023% at 30 °C.
