GE Mark VI Terminal Contact Board IS200TBCIH1B

Product Overview

The GE IS200TBCIH1B (IS200TBCIH1B) operates as a heavy-duty Contact Terminal Board within the Speedtronic Mark VI turbine control framework. This 100% brand new, authentic factory-packaged board provides the primary physical interface for field wiring, routing discrete inputs and dry contact signals directly to the control rack. Infrastructure facilities deploy this termination block inside power generation plants, chemical refineries, and heavy industrial mills to centralize complex wire networks. The robust physical circuit paths handle high-voltage excitation signals and deliver clean electrical isolation between the external plant environment and sensitive control processors. By stabilizing terminal junctions and providing direct diagnostic access loops, this board simplifies field commissioning, stops loose-wire noise anomalies, and secures system runtime to mitigate costly unprogrammed process shutdowns.

Part Number Breakdown

The structural alpha-numeric designations within the IS200TBCIH1B model number detail specific hardware traits and design iterations specified by General Electric:

• IS200: Designates the standard printed circuit board (PCB) base construction profile within the Mark VI product group.

• TBCI: Identifies the functional acronym representing the Terminal Block Contact Input board configuration.

• H1: Classifies the specific assembly block variation, specifying the number of physical terminal screws and connector headers.

• B: Highlights the certified factory revision layer, denoting component-level hardware refinements.

Technical Specifications

Engineering Advantages

The physical build and design choices of the IS200TBCIH1B systematically solve terminal wiring and interference pain points common to harsh turbine environments:

• High-Barrier Screwed Terminals: Industrial enclosures often experience intense vibration profiles from adjacent gas turbines or compressors. This board features rugged, high-barrier screw terminal strips that clamp conductors tightly. This design completely eliminates mechanical wire backing-out issues and maintains steady gas-tight connections over years of continuous operation.

• Integrated Surge and Noise Suppression: Long field cable runs from remote limit switches collect electromagnetic interference (EMI) and lightning transients. The board integrates localized metal oxide varistors (MOVs) and high-frequency RC filtering networks on every input line. These components absorb high-energy voltage spikes and suppress cross-talk noise before it can corrupt downstream digital logic.

• Streamlined Diagnostic Test Points: To speed up troubleshooting sequences, the board layout provides dedicated, exposed voltage test points adjacent to each input channel. Technicians verify loop voltage metrics or inject simulation signals safely without stripping field insulation or disturbing active factory wires, cutting down loop-checking times.

FAQs

• Does the IS200TBCIH1B board include the factory-installed terminal screws?

  Yes. This module arrives in 100% brand new, original factory-sealed condition with all terminal block assemblies, terminal screws, and multi-pin D-sub connectors pre-soldered and fully tested by General Electric.

• Can I use the IS200TBCIH1B with standard Mark VIe distributed I/O packs?

  While this board originated within the standard Mark VI cabinet architecture, certain migration setups and terminal board layouts allow cross-linking with specific Mark VIe packs. You must check your system's engineering control drawing sheets to verify exact cable and signaling compatibility.

• What is the recommended torque specification for the field wiring screws?

  To ensure proper electrical contact and prevent thread damage, tighten the barrier terminal block screws using a calibrated screwdriver to a torque range of 0.56-0.79 Nm (5-7 in-lbs).
