Honeywell 900C72R-0100-43 C70R CPU Controller Module

Product Overview

The Honeywell 900C72R-0100-43 is a C70R CPU Controller Module for the Honeywell ControlEdge HC900 platform. The C70R is a high-performance controller with redundancy capabilities, supporting large-scale process control applications with up to 64 control loops and extensive I/O capacity. Featuring a quad-core ARM Cortex-A9 processor, 512 MB RAM, and 1 GB Flash memory, this module delivers robust processing power for complex control strategies, batch processing, and advanced automation applications.

Key Features

• Quad-Core ARM Cortex-A9 Processor: High-performance processing for demanding applications
• 512 MB RAM / 1 GB Flash: Ample memory for large control strategies and data logging
• Redundancy Ready: Supports CPU redundancy for fault-tolerant control
• Dual Ethernet Ports: Redundant network connectivity
• USB & RS-232 Ports: Local programming and device connectivity
• Real-Time Operating System: Deterministic control execution

Technical Specifications

• Model: 900C72R-0100-43
• Type: C70R CPU Controller Module
• Series: ControlEdge HC900
• Processor: Quad-core ARM Cortex-A9
• RAM: 512 MB
• Flash Memory: 1 GB
• Control Loops: Up to 64
• I/O Capacity: Extensive (refer to system documentation for limits)
• Communication: 2× Ethernet, 1× USB, 1× RS-232
• Programming: CODESYS IEC 61131-3, C/C++
• Dimensions: 137 mm H × 38.1 mm W (5.4" H × 1.5" W)
• Weight: ~320 g
• Mounting: Chassis slot mount
• Operating Temperature: 0°C to +60°C
• Approvals: CE, UL, CSA

Installation Guide

1. Rack Preparation: Install in HC900 CPU rack or redundant CPU rack (900RR0 series)
2. Power Connection: Connect rack power supply (900P01 series)
3. Network Setup: Configure dual Ethernet ports for redundant network topology
4. Programming: Install USB driver and connect via ControlEdge Builder
5. Redundancy Configuration: For redundant setup, pair with second C70R module and configure in software
6. I/O Scanning: Configure I/O scanner modules (900S50/900S75) for rack communication

FAQ

Q: What is the difference between C70 and C70R?
A> The "R" suffix indicates redundancy-ready capability. The C70R can be configured in a redundant pair for fault-tolerant control, while the standard C70 is for single-CPU applications.

Q: Can the 900C72R-0100-43 be used for SIL-rated safety applications?
A> No. For SIL-rated safety control, use the 900C70S-0360-00 Safety CPU module series.

Q: What is the maximum I/O capacity?
A> The C70R supports extensive I/O capacity. Refer to the latest HC900 system documentation for exact limits based on module configuration and scan time requirements.

Selection Tips

• Use 900C72R-0100-43 for large-scale process control requiring redundancy
• Pair with 900RR0-0300 redundant CPU rack for full redundancy
• Verify ControlEdge Builder version supports C70R firmware
• For safety applications, migrate to 900C70S Safety CPU series
