Honeywell CC-TAIX61 51307077-175 6-inch High-Level Analog Input IOTA

Overview

The Honeywell CC-TAIX61 (Part Number: 51307077-175) is a 6-inch High-Level Analog Input Termination Assembly (IOTA) with integrated HART capability designed for the Experion PKS Series C platform. It serves as the physical interface to route 16 analog field signals into the corresponding input module while enabling digital HART protocol communication.

Technical Specifications

• Product Type: HART Analog Input Module Termination Assembly
• Model Code: CC-TAIX61
• Part Number: 51307077-175
• Manufacturer: Honeywell
• Channel Capacity: 16 Channels
• Signal Compatibility: High-Level Analog Inputs (4-20 mA / 1-5 V DC) with HART support
• IOTA Size: 6 inches
• Redundancy Support: No (Non-Redundant / Single slot layout)
• Conformal Coating: Yes (ISA-S71.04 Class G3 Compliant)

Installation Notes

• Snap the CC-TAIX61 IOTA firmly onto the designated carrier DIN rail inside the enclosure.
• Connect the IOTA grounding strip directly to the enclosure's master common ground bar to prevent electrical noise on the 4-20 mA and HART data paths.
• Wire the 16 analog transmitter loops to the screw terminals, ensuring proper loop power sourcing.
• Check the multi-pin connector on the analog input module for bent pins before pressing it vertically onto the board interface slot.
