Honeywell FS-TSDO-04UNI Safe Digital Output FTA (4 CH, Universal)

Product Overview

The Honeywell FS-TSDO-04UNI is a Safe Universal Digital Output Field Termination Assembly (FTA) providing 4 channels of configurable digital output for Honeywell Safety Manager systems. This universal FTA supports multiple output configurations, enabling flexible actuator control for diverse safety applications including solenoid valves, motor controls, and signaling devices.

Key Features

• 4 Universal Digital Outputs: Configurable for various output types and voltages
• Flexible Configuration: Supports multiple output modes for diverse actuator requirements
• Short-Circuit Protection: Per-channel electronic protection
• System Interconnection: SIC cable interface to redundant SDO I/O modules
• Compact Design: Reduced channel count for smaller actuator groups
• DIN Rail Mounting: Universal snap-in for TS32/TS35 rails

Technical Specifications

• Model: FS-TSDO-04UNI
• Type: Safe Universal Digital Output FTA
• Channels: 4 digital outputs
• Output Type: Universal (configurable)
• Voltage: 24 VDC (standard)
• Current: Per-channel rated
• Protection: Short-circuit, overload
• DIN Rail: TS32 / TS35 × 7.5
• Wire Size: Max 2.5 mm² (AWG 14)
• Operating Temperature: -40°C to +70°C
• Approvals: CE, TÜV, UL, CSA, FM

Installation Guide

1. Configuration: Set output type via Safety Manager engineering software before installation
2. DIN Rail Mount: Snap FTA onto TS32/TS35 rail
3. Actuator Wiring: Connect field actuators to screw terminals per configuration
4. SIC Cable: Connect system interconnection cable to paired I/O module
5. Verification: Test each channel output after configuration to confirm proper operation

FAQ

Q: What makes this "universal"?
A: The FS-TSDO-04UNI supports configurable output modes, allowing adaptation to different actuator types and voltage requirements within the supported range.

Q: How many actuators can this FTA control?
A: This FTA has 4 output channels, controlling up to 4 actuators. For 8-channel applications, use FS-TSDO-0824.

Selection Tips

• Use when fewer output channels are needed or actuator types vary
• Verify output configuration compatibility with field devices
• Consider channel count requirements vs. cost optimization
