Honeywell SPS5713 51199930-100 Series SPS Main Power Rack

Product Description

The SPS5713 (Part Number: 51199930-100) is the main power rack/backplane for the Honeywell Experion PKS Series C System Power Supply (SPS) infrastructure. It serves as the centralized electrical backbone for C300 controllers and Series C I/O clusters, providing a reliable platform to house multiple SPS modules (e.g., SPS5710) and distribute DC power with high availability.

Engineered for redundancy and scalability, the SPS5713 allows multiple power modules to operate in parallel, enabling load sharing and bumpless failover. Its rugged design simplifies cable management, enhances system diagnostics, and supports the demanding environments of refineries, power plants, and critical process control facilities.

Technical Specifications

Application Scenarios

• Centralized Power Distribution: Acts as the main hub for multi-node C300 controller cabinets.

• High-Availability Systems: Enables redundant backplane support for Emergency Shutdown (ESD) or critical process loops.

• System Expansion: Adds slots for additional SPS modules to increase I/O density.

• Infrastructure Maintenance: Replaces aging power backplanes to maintain electrical integrity in DCS nodes.

Frequently Asked Questions

How many power modules can the SPS5713 rack accommodate?
The SPS5713 can typically house 3 to 4 SPS modules, depending on cabinet layout, allowing for flexible power scaling and full redundancy.

Does this rack include the power supply modules?
No. The SPS5713 is the empty rack/backplane assembly. Power supply modules, such as the SPS5710, must be purchased separately.
