IC200MDL650 | GE Fanuc VersaMax 32-Point 24 VDC Positive Logic Input Module

Product Description

The GE Fanuc VersaMax IC200MDL650 is a discrete input module designed for monitoring DC signals in VersaMax PLC systems. It provides 32 input points arranged in four groups of eight, with configurable filter times and group-to-group isolation for reliable operation. Each input channel is equipped with LED indicators, ensuring clear diagnostics and system visibility. Compact and efficient, this module is well-suited for industrial automation environments requiring high-density DC input monitoring.

Technical Specifications

• Manufacturer: GE Fanuc Emerson

• Model / Part Number: IC200MDL650

• Product Line: VersaMax I/O

• Product Type: Discrete Input Module

• Weight: 0.69 lbs (0.31 kg)

• Number of Inputs: 32 points (4 groups of 8 channels each)

• Nominal Input Voltage: 24 VDC positive logic

• Input Signal Range: 0–30 VDC

• Input Impedance: 10 kΩ

• On-State Voltage: 15–30 VDC

• Off-State Voltage: 0–5 VDC

• On-State Current: 2.0–5.5 mA

• Off-State Current: ≤ 0.5 mA

• Backplane Current Consumption: 50 mA maximum at 5 VDC

• Response Time (Default): 0.5 ms

• Configurable Filter Times: 0 ms, 1.0 ms, or 7.0 ms

• Isolation:

• Group-to-group: 250 VAC continuous, 1500 VAC for 1 minute

• Point-to-point: None

• LED Indicators: One LED per input point, plus OK LED

Application Scenarios

The IC200MDL650 is ideal for monitoring 24 VDC signals in distributed control systems. It is commonly used in machine automation, packaging equipment, and process control applications where high-density input monitoring and fast response times are required.

FAQ

Q: How many input points does the IC200MDL650 provide?  A: 32 discrete input points, divided into four groups of eight.

Q: What is the nominal input voltage?  A: 24 VDC positive logic.

Q: Does the module provide isolation?  A: Yes, group-to-group isolation is supported, but point-to-point isolation is not.
