INIIT13 | ABB Bailey Infi 90 Communication Module

ABB Bailey INIIT13 Infi-Net to Infi-Net Transfer Module

The ABB Bailey INIIT13 is an Infi-Net to Infi-Net Transfer Module for the INFI 90 distributed control system. It provides high-speed data transfer between Infi-Net communication networks, enabling seamless integration and data exchange between multiple INFI 90 and Net 90 control environments.

Key Specifications

• Part Number: INIIT13
• Product Type: Infi-Net to Infi-Net Transfer Module
• Series: INFI 90 / Net 90 / Symphony
• Manufacturer: ABB / Bailey Controls
• Function: Facilitates high-speed data transfer between Infi-Net systems
• Dimensions: 330 × 51 × 178 mm (13.0" × 2.0" × 7.0")
• Weight: 0.18 kg (0.40 lbs)
• Operating Temperature: 0°C to 60°C
• Storage Temperature: -20°C to 85°C
• Humidity: 5% to 95% non-condensing
• Mounting: INFI 90 MMU rack slot
• Origin: Sweden

Features & Benefits

1. High-Speed Data Transfer: Enables real-time data exchange between independent Infi-Net networks.
2. Network Bridge: Acts as a communication gateway, extending DCS architecture across multiple subnets.
3. Seamless Integration: Compatible with INFI 90, Net 90, and Symphony Harmony systems.
4. Compact Design: Single-width module minimizes rack space requirements.

Applications

• Multi-plant DCS integration
• Subnet-to-subnet data bridging
• Legacy INFI 90 to modern Symphony migration
• Remote site communication linking

FAQ

Q: What is the difference between INIIT13 and INICT12?
A: The INIIT13 is an Infi-Net to Infi-Net transfer module for network-to-network bridging. The INICT12 is an Infi-Net to Computer transfer module for host computer interfaces. They serve different communication roles.

Q: Does INIIT13 support Ethernet communication?
A: The INIIT13 operates over Infi-Net protocol. For Ethernet integration, use INICI12/INICI13 or IET800 modules.

Installation Guide

1. Install INIIT13 into INFI 90 MMU rack slot.
2. Connect Infi-Net cables from both networks to the module terminals.
3. Configure network addressing and routing tables via engineering software.
4. Verify data transfer by monitoring network diagnostics.
5. Test bidirectional communication between subnets.

Selection Tips

• Network Topology: Confirm your system requires Infi-Net bridging before ordering INIIT13.
• Data Rate: Verify Infi-Net bandwidth requirements are met by the transfer module capacity.
