Isolated Power Supply Schneider Electric BMXCPS2010
  • Isolated Power Supply Schneider Electric BMXCPS2010
  • Isolated Power Supply Schneider Electric BMXCPS2010
  • Isolated Power Supply Schneider Electric BMXCPS2010
Isolated Power Supply Schneider Electric BMXCPS2010

Schneider

Isolated Power Supply Schneider Electric BMXCPS2010

In stock

  • Manufacturer: Schneider

  • Product No.: BMXCPS2010

  • Product Type: Isolated Power Supply

  • Product Origin: France

  • Payment:T/T, Western Union

  • Weight: 320g

  • Shipping port: Xiamen

  • Warranty: 12 months

Special offer ends!
00 :
00 :
00

Product Description

The BMXCPS2010 is a DC-to-DC isolated power supply module for the Schneider Electric Modicon X80 platform. Designed for 24 V DC primary power sources, it provides isolated secondary voltages for the backplane, protecting processors and I/O modules from voltage spikes and common-mode noise. Ideal for battery-powered, solar, or DC-only industrial systems.

Technical Specifications

Item Specification
Input Voltage 24 V DC (18–31.2 V DC)
Input Current 1 A @ 24 V DC
Inrush Current 30 A @ 24 V DC
Total Secondary Power 20 W
3.3 V DC Backplane Logic 8.3 W
24 V DC Backplane I/O & CPU 16.8 W
Protection (Primary) Internal fuse (non-serviceable)
Protection (Secondary) Overload, overvoltage, short-circuit
Power Dissipation ≤ 8.5 W
Isolation > 100 MΩ @ 500 V DC (primary to secondary)
Status Indicator Green LED (Power OK)
Diagnostics Alarm relay contact (NC)
Operating Temperature 0–60 °C

Typical Applications

  • Remote battery-powered or solar PLC sites

  • Oil & gas wellhead monitoring

  • Marine vessel control systems

  • Telecom or RTU installations

  • Solar-powered water irrigation controllers

Notes

  • Compatible with M340 and M580 backplanes

  • Internal fuse is non-serviceable; replace module if fuse blows

  • Handles short DC interruptions with 1–10 ms hold-up time depending on load
