KL3103X1-LS1 | Emerson DeltaV | RTD Input CHARM
  • KL3103X1-LS1 | Emerson DeltaV | RTD Input CHARM
  • KL3103X1-LS1 | Emerson DeltaV | RTD Input CHARM
  • KL3103X1-LS1 | Emerson DeltaV | RTD Input CHARM
KL3103X1-LS1 | Emerson DeltaV | RTD Input CHARM

Emerson

KL3103X1-LS1 | Emerson DeltaV | RTD Input CHARM

10 left

  • Manufacturer: Emerson

  • Product No.: KL3103X1-LS1

  • Product Type: RTD Input CHARM

  • Product Origin: USA

  • Payment:T/T, Western Union

  • Weight: 200g

  • Shipping port: Xiamen

  • Warranty: 12 months

Special offer ends!
00 :
00 :
00

Product Description

The KL3103X1-LS1 converts RTD resistance signals into precise digital values for accurate temperature monitoring.
Additionally, the module maintains stable excitation current, which improves measurement consistency across varying conditions.
Its compact CHARM design allows dense installation and simplifies cabinet layout optimization.
Furthermore, Emerson integrates isolation protection to reduce electrical noise and enhance system reliability.

Technical Specifications

Parameter Detailed Specification
Model KL3103X1-LS1
Manufacturer Emerson
Series DeltaV CHARM I/O System
Module Type RTD Input CHARM Module
Input Signal Type Resistance Temperature Detector (RTD) input
Supported Sensor Types Pt100, Pt200, Pt1000 (industry-standard RTDs)
Measurement Range -200°C to +850°C depending on RTD type
Input Channels Single-channel CHARM
Conversion Method Resistance-to-digital temperature conversion
Resolution 16-bit high-resolution signal conversion
Measurement Accuracy ±0.1% of span
Excitation Current Low, constant excitation current for stable RTD measurement
Signal Update Rate Fast real-time sampling for process control
CHARM Bus Power +6.3 V DC at approximately 32 mA
Field Circuit Power +24 V DC at approximately 16 mA
Energy Storage Integrated capacitors for signal smoothing and transient stability
Isolation Electrical isolation between field input and system backplane
Noise Immunity High resistance to EMI and industrial electrical interference
Interface Type CHARM baseplate connection
Mounting Method Plug-in installation on DeltaV CHARM carrier
Dimensions (L×W×H) Approx. 5.1 × 1.9 × 3.2 cm
Alternative Dimensions Approx. 0.8 × 7.6 × 11.4 cm (housing format reference)
Weight Approx. 0.03 kg
Operating Temperature -40°C to +70°C
Storage Temperature -40°C to +85°C
Relative Humidity 5%–95% non-condensing
Environmental Rating ISA-S71.04 Class G3 (harsh industrial environments)
Protection Features Overvoltage tolerance and input fault detection
Internal Components Precision resistors, ADC converters, and filtering capacitors
System Compatibility Emerson DeltaV distributed control system



FAQ

Q1: Is the KL3103X1-LS1 brand new and original?
A1: Yes, we provide brand new original modules with guaranteed authenticity and reliable performance.

Q2: Do you have KL3103X1-LS1 in stock?
A2: Yes, we keep stock available and support fast processing for urgent and bulk orders.

Q3: How long does shipping take for KL3103X1-LS1?
A3: We ship within 3 days to 2 weeks depending on order size and logistics arrangements.

Q4: Which logistics services do you use?
A4: We commonly use DHL and similar international carriers for fast and secure delivery.

Q5: What sensor types does KL3103X1-LS1 support?
A5: The module supports RTD sensors such as Pt100, Pt200, and Pt1000 for temperature measurement.

Q6: Can I return the product if there is a quality issue?
A6: Yes, we support returns within 30 days if any quality issue occurs after delivery.


Return policy

​We aim to provide reliable products and a smooth purchasing experience. If there is a problem with your order, please contact us and we will assist according to our Refund Policy.
Shipping

We provide international shipping options to meet different delivery requirements. Please review details regarding methods and timelines in our Shipping Policy.
Warranty

We provide a 12-month warranty for all products, subject to normal use and proper installation.
