MVI46-DFNT | Prosoft Communication module | Allen Bradley SLC500

Product Overview

The ProSoft MVI46-DFNT is an EtherNet/IP Client/Server Network Interface Module designed for the Allen-Bradley SLC 500 processor platform. It enables SLC 500 processors to easily interface with other EtherNet/IP compatible devices, providing a cost-effective upgrade path for legacy SLC systems to modern Ethernet-based control networks. The MVI46-DFNT occupies a single slot in the SLC 500 rack and requires minimal configuration.

Key Technical Specifications

• Product Type: EtherNet/IP Client/Server Network Interface Module
• Series: ProSoft MVI46
• Platform: Allen-Bradley SLC 500
• Configuration Port: 1 × RJ45 Serial (P1)
• Ethernet Port: 1 × RJ45 (EtherNet/IP)
• Protocol Support: EtherNet/IP Client/Server
• Function: Network interface for SLC 500 to EtherNet/IP devices
• UPC/GTIN: 00886739894192
• Status: Current Product
• Origin: USA

Key Features

• EtherNet/IP Connectivity: Modern Ethernet network integration for SLC 500
• Client/Server Operation: Initiate and respond to EtherNet/IP connections
• Easy Configuration: Simple setup via serial configuration port
• Legacy Upgrade: Extends SLC 500 system life without processor replacement

Applications

• SLC 500 to ControlLogix communication
• SLC 500 to modern HMI/SCADA integration
• Plant-wide Ethernet network connectivity
• Legacy system modernization projects

Installation Guide

1. Install in SLC 500 processor rack
2. Connect EtherNet/IP cable to RJ45 port
3. Connect serial configuration cable to P1
4. Configure IP address via terminal software
5. Set up client/server connections

FAQ

Q: What SLC 500 processors are compatible?
A: Compatible with SLC 5/03, SLC 5/04, and SLC 5/05 processors.

Q: Can it communicate with CompactLogix?
A> Yes, any EtherNet/IP compatible device including CompactLogix and ControlLogix.

Model Selection Tips

• MVI46-DFNT = EtherNet/IP for SLC 500
• For SLC 500 Modbus, use MVI46-MCM
• For SLC 500 HART, use MVI46-HART
• Verify SLC 500 rack slot availability
