PM863K02 | ABB AC 800M HI Redundant Processor Unit Kit

Product Overview

The ABB PM863K02 (3BSE088382R1) is a High Integrity (HI) redundant Processor Unit Kit for safety-critical AC 800M applications. It pairs two PM863 processors for SIL-certified redundant control when used with SM811/SM812 safety modules and certified S800 I/O.

Key Specifications

• Manufacturer: ABB
• Part Number: PM863K02 (3BSE088382R1)
• Product Type: AC 800M HI Redundant Processor Unit Kit
• CPU: 2× MPC862P @ 96 MHz
• Memory: 32 MB SDRAM per CPU
• System: AC 800M HI / System 800xA
• Safety Rating: SIL2/SIL3 capable (with SM811/SM812)
• Redundancy: Hot-standby CPU redundancy
• Switchover Time: Max 10 ms
• Power Supply: 24 V DC

Applications

• Safety instrumented systems (SIS)
• Emergency shutdown (ESD) systems
• Burner management systems
• High-integrity process control

FAQ

Q: What makes PM863 different from PM864A/PM866A?
A: PM863 is specifically designed for High Integrity applications with dedicated safety firmware and compatibility with SM811/SM812 safety modules.

Q: Is PM863K02 certified for SIL3?
A: SIL3 is achievable with PM867/SM812 configurations. PM863 supports HI applications; verify specific SIL requirements with ABB documentation.

Installation Guide

1. Install in a dedicated safety cabinet with appropriate segregation.
2. Mount both processors and safety modules per ABB HI guidelines.
3. Use shielded cables for all safety-critical connections.
4. Perform proof tests per IEC 61508/61511 schedules.

Selection Tips

• Confirm safety requirements (SIL level) before selecting HI hardware.
• Use only SIL-certified S800 I/O modules (e.g., DI880, AI880A) for safety loops.
• Engage ABB safety engineering for SIL verification.
